GLSSC200 by Dixon Valve | Liquid Filled Gauge | Center Back Mount | 2-1/2" Face | 1/4" Center Back Mount | 0-200 PSI Range | Stainless Steel

Save $32.82

$82.05

$82.05 - $82.05

$82.05

$49.23

$49.23 - $49.23

$49.23

Dixon Valve
Dixon® Gauge | Liquid Filled Gauge | Center Back Mount

Designed for severe service applications, providing the corrosion resistance and durability of a permanently sealed gauge.

Specifications for Variant SKU: GLSSC200 Dixon
Series:	GLSSC Series

Features:
± 2-1-2% accuracy. 1/4" NPT center back mount stainless connector.
Materials:
Window: poly carbonate Case and crimp ring: 304 stainless Glycerin filled
Specifications:
Ambient temperature range: 20°F to 158°F (-7°C to 70°C)
Term Meanings:
Figure Interval: Figure Interval (Increments between PSI numbers on gauge face). Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).

2-1/2" Face 1/4" Center Back Mount Part Number	PSI Range	Figure Interval	Minor Gradient
GLSSC100	0-100 PSI	20	2
GLSSC160	0-160 PSI	20	2
GLSSC200	0-200 PSI	50	5

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
