GSS3000-4 by Dixon Valve | Dry Gauge | Lower Mount | 4" Face | 1/4" Lower Mount | 0-3000 PSI Range | Stainless Steel

Save $5.13

$67.08

$67.08 - $67.08

$67.08

$61.95

$61.95 - $61.95

$61.95

Dixon Valve
Dixon® Gauge | Dry Gauge | Lower Mount

Designed for severe service applications, providing the corrosion resistance and durability of a permanently sealed gauge.

Quantity

Specifications for Variant SKU: GSS3000-4 Dixon
Series:	GSS-4 Series

Features:
1/4" NPT lower mount stainless connector. 1.6% accuracy, exceeds ASME B.40.100 Grade B.
Materials:
304 series stainless case. Polycarbonate window, 3-1/2" across. 316L stainless bourdon tube and socket, polyester segment.
Specifications:
Temperature range: 20°F to 150°F (-7°C to 66°C)
Term Meanings:
Figure Interval: Figure Interval (Increments between PSI numbers on gauge face). Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).

4" Face 1/4" Lower Mount Part Number	PSI Range	Figure Interval	Minor Gradient
GSS15-4	0-15 PSI	3	0.5
GSS30-4	0-30 PSI	5	0.5
GSS60-4	0-60 PSI	10	1
GSS100-4	0-100 PSI	20	2
GSS160-4	0-160 PSI	20	2
GSS200-4	0-200 PSI	40	5
GSS300-4	0-300 PSI	50	5
GSS400-4	0-400 PSI	50	10
GSS600-4	0-600 PSI	100	10
GSS1000-4	0-1000 PSI	200	10
GSS1500-4	0-1500 PSI	200	20
GSS3000-4	0-3000 PSI	500	50
GSS5000-4	0-5000 PSI	1000	100
GSS10000-4	0-10000 PSI	2000	200
