GSS600 by Dixon Valve | Dry Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-600 PSI Range | Stainless Steel

Save $31.25

$78.13

$78.13 - $78.13

$78.13

$46.88

$46.88 - $46.88

$46.88

Dixon Valve
Dixon® Gauge | Dry Gauge | Lower Mount

Designed for severe service applications, providing the corrosion resistance and durability of a permanently sealed gauge.

Specifications for Variant SKU: GSS600 Dixon
Series:	GSS Series

Features:
1/4" NPT lower mount stainless connector. ± 2-1-2% accuracy
Materials:
304 stainless steel case and crimp ring. Polycarbonate window. 316 stainless bourdon tube and socket.
Specifications:
Ambient temperature range: 20°F to 158°F (-7°C to 70°C)
Term Meanings:
Figure Interval: Figure Interval (Increments between PSI numbers on gauge face). Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).

2-1/2" Face 1/4" Lower Mount Part Number	PSI Range	Figure Interval	Minor Gradient
GSS15	0-15 PSI	3	0.2
GSS30	0-30 PSI	5	0.5
GSS60	0-60 PSI	10	1
GSS100	0-100 PSI	20	2
GSS160	0-160 PSI	20	2
GSS200	0-200 PSI	50	5
GSS300	0-300 PSI	50	5
GSS400	0-400 PSI	100	10
GSS600	0-600 PSI	100	10
GSS1000	0-1000 PSI	200	20
GSS1500	0-1500 PSI	300	20
GSS2000	0-2000 PSI	500	50
GSS3000	0-3000 PSI	500	50
GSS5000	0-5000 PSI	1000	100
GSS10000	0-10000 PSI	2000	200

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
