HEPS-6X8 by Campbell Fittings | Expander | 1-1/2" Male NPT Thread x 2" Hose Barb | Plated Steel

Name: HEPS-6X8 by Campbell Fittings | Expander | 1-1/2" Male NPT Thread x 2" Hose Barb | Plated Steel
Brand: Campbell Fittings
SKU: HEPS-6X8 Campbell Fittings
Price: 19.05 USD
Availability: InStock

$16.89 - $16.89

$16.89

$19.05

$19.05 - $19.05

$19.05

by Campbell
Combination Nipples & Menders:HEPS Expander Nipple

Quantity

Specifications for Variant SKU: HEPS-6X8 Campbell Fittings
Series:	HEPS Series
Shape (Orientation):	Straight
Ends Configuration:	1-1/2in Male NPT, 2in Hose Barb
Material(s):	Plated Steel

Recommended Use:	Liquid, bulk handling, low pressure air
Recommended Hose Attachments:	Sleeves Preformed Bands Clamps
Features and Benefits:	Maximum number of serrations for maximum holding power Long lead serration for easier hose insertion Formed hex wrench area on 3/4" through 1-1/2" combination nipples for easier installation


Part Number	Hose Size
HEPS-2X3	1/2" x 3/4"
HEPS-3X4	3/4" x 1"
HEPS-4X5	1" x 1-1/4"
HEPS-5X6	1-1/4" x 1-1/2"
HEPS-5X8	1-1/4" x 2"
HEPS-6X8	1-1/2" x 2"
HEPS-8X10	2" x 2-1/2"
HEPS-10X12	2-1/2" x 3"
HEPS-12X16	3" x 4"

Campbell Fittings

Campbell Fittings offers a range of hose fittings, couplings, ferrules, and sleeves, for applications across a variety of industries.
