HESS-6X8 by Campbell Fittings | Expander | 1-1/2" Male NPT Thread x 2" Hose Barb | 316 Stainless Steel

HESS-6X8 by Campbell Fittings | Expander | 1-1/2" Male NPT Thread x 2" Hose Barb | 316 Stainless Steel

Save $49.23 Save $49.23
$123.08
$123.08 - $123.08
$123.08
$73.85
$73.85 - $73.85
$73.85

by Campbell
Combination Nipples & Menders:HESS Expander Nipple
Specifications for Variant SKU: HESS-6X8 Campbell Fittings
Series: HESS Series
Shape (Orientation): Straight
Ends Configuration: 1-1/2in Male NPT, 2in Hose Barb
Material(s): 316 Stainless Steel
Recommended Use:
  • Liquid, bulk handling, low pressure air
Recommended Hose Attachments:
  • Sleeves
  • Preformed Bands Clamps
Features and Benefits:
  • Maximum number of serrations for maximum holding power
  • Long lead serration for easier hose insertion
  • Formed hex wrench area on 3/4" through 1-1/2" combination nipples for easier installation
Part Number Hose Size
HESS-2X3 1/2" x 3/4"
HESS-3X4 3/4" x 1"
HESS-4X5 1" x 1-1/4"
HESS-4X6 1" x 1-1/2"
HESS-5X6 1-1/4" x 1-1/2"
HESS-5X8 1-1/4" x 2"
HESS-6X8 1-1/2" x 2"
HESS-8X10 2" x 2-1/2"

Campbell Fittings

Campbell Fittings offers a range of hose fittings, couplings, ferrules, and sleeves, for applications across a variety of industries.
