PHV5050 by Dixon Valve | P-HV-Series | Low Pressure Spring Driven Hose Reel - with Hose | 1/2" Hose ID | 50ft Hose Length

Name: PHV5050 by Dixon Valve | P-HV-Series | Low Pressure Spring Driven Hose Reel - with Hose | 1/2" Hose ID | 50ft Hose Length
Brand: Dixon
SKU: PHV5050 Dixon
Price: 728.17 USD
Availability: InStock

Save $485.45

$1,213.62

$1,213.62 - $1,213.62

$1,213.62

$728.17

$728.17 - $728.17

$728.17

Dixon Valve
P-HV-Series | Low Pressure Spring Driven Hose Reel with Hose

Made in the U.S.A.

Specifications for Variant SKU: PHV5050 Dixon
Series:	P-HV-Series

Applications:
Air, Water
Construction:
Rust inhibiting, powder coat finish. Professional grade, heavy-duty construction. Non-corrosive stainless-steel spring, pawl and zinc plated ratchet. Enclosed factory tuned and matched cartridge-style spring motor. Made in the U.S.A.
Features:
Rolled edges and ribbed discs provide strength and safety. Hybrid (PVC & Rubber) bright yellow hose with a white glossy strip. Superior visibility, increased hose flexibility, enhanced kink resistance, and reduced coil memory. Solid one-piece, heavy gauge 1/4" steel base and support post for maximum stability. 1" solid steel axle and lubricated precision bearings for smooth rotation. Multi-position lock ratchet mechanism secures hose at desired length.
Specifications:
Maximum temperature 150°F (66°C)

Part Number	Hose I.D.	Hose Length	Service	Working Pressure PSI @70°F
PHV3850	3/8"	50ft	Air / Water	300 PSI
PHV5050	1/2"	50ft	Air / Water	300 PSI

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
