PP8TPL by Parker | TrueSeal™ Accessories | 1/2" Plug | White | Polypropylene

PP8TPL by Parker | TrueSeal™ Accessories | 1/2" Plug | White | Polypropylene

Save $0.20 Save $0.20
$2.55
$2.55 - $2.55
$2.55
$2.35
$2.35 - $2.35
$2.35

by Parker Hannifin
TrueSeal™ Fittings:TPL - Plug
Specifications for Variant SKU: PP8TPL Parker
Brand: TrueSeal™
Series: TPL Series
Shape (Orientation): No Orientation
Material(s): Polypropylene
Seal Material(s): EPDM
Special Properties: Food Grade, Filtration
Product Features:
  • Acetal and Black Polypropylene (EPDM seals and metal gripping collet standard
  • White Polypropylene (EPDM seals and plastic gripping collet standard
  • Black Kynar (Fluorocarbon (FKM) seals and black kynar metal gripping collet standard
  • Gripping ring with stainless steel bite edge or with an engineered thermoplastic bite edge
  • FDA compliant, NSF/ANSI 51
  • Gray acetal and Black Polypropylene NSF/ANSI/CAN 61
Markets:
  • Food
  • Potable Water
  • Chemical
  • Filtration
Applications:
  • Air
  • Water
  • Soft Drinks
  • Beer
  • Wine
  • Dyes
  • Vacuum
Pressure Range: Acetal and Kynar:
  • 1/4", 5/16", 3/8" Vacuum to 300 PSI (20.7 bar) 1/2" Vacuum to 250 PSI (17.2 bar)
    • Polypropylene:
  • 1/4", 3/8", 1/2" Vacuum to 150 PSI (10.3 bar)
Temperature Range:
Acetal:
  • -20° to +180° F (-28.9° to +82.2° C)
    		•
    Polypropylene:
  • 0° to +225° F (-17.8° to +107.2° C)
    		•  Kynar:
  • 0° to +275° F (-17.8° to +135° C)
    		•
    Compatible Tubing:
    • Polyethylene
    • Polypropylene**
    • Nylon**
    • Vinyl+
    • Fluoropolymer**
    • Polyurethane+
    • *Kynar®

    * Registered trademark of The Arkema Group.
    ** Metal gripper required (-MG & -HBLK suffix).
    + Tube Support required.

    Gray Acetal Black PPL White PPL Black Kynar Fitting Size Overall Length (L)
    A4TPL PPB4TPL PP4TPL FB4TPL 1/4" .88"
    A6TPL PPB6TPL PP6TPL FB6TPL 3/8" 1.45"
    A8TPL PPB8TPL PP8TPL FB8TPL 1/2" 1.50"
