PPC125 by Dixon Valve | Cam & Groove Reducer (Jump Size) Coupler | Type C | 1-1/2" Coupler x 1-1/4" Hose Shank | Polypropylene

Name: PPC125 by Dixon Valve | Cam & Groove Reducer (Jump Size) Coupler | Type C | 1-1/2" Coupler x 1-1/4" Hose Shank | Polypropylene
Brand: Dixon
SKU: PPC125 Dixon
Price: 8.95 USD
Availability: InStock

Save $5.97

$14.92

$14.92 - $14.92

$14.92

$8.95

$8.95 - $8.95

$8.95

Dixon Valve
Cam & Groove | Type C Coupler | Coupler x Hose Shank

Designed for use with liquids.

Specifications for Variant SKU: PPC125 Dixon
Shape (Orientation):	Straight
Cam Type:	Type C
Ends Configuration:	1-1/2in Female Cam & Groove, 1-1/4in Hose Barb
Material(s):	Polypropylene
Seal Material(s):	EPDM

Features:
1/2" couplers and adapters will interchange with 3/4" couplers and adapters, only the threads and barbs are 1/2". 1-1/4" couplers and adapters will interchange with 1-1/2" couplers and adapters, only the threads and barbs are 1-1/4".
Construction:
Manufactured from glass-filled polypropylene. 304 stainless steel handles. EPDM gaskets. 304 stainless steel pins.
Specifications:
Maximum operating pressure: 125 PSI (1/2" - 1"), 100 PSI (1-1/4" - 2"), 60 PSI (3"), and 50 PSI (4"); recommendations based on the use of mating Dixon® fittings at an ambient temperature of 70°F (21°C) with standard seal installed.
How It Works:
To make a connection, simply slide the adapter into the coupler and with normal hand pressure, press the cam levers down. Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter.
Safety Notes:
Under no circumstances should cam and groove couplings be used for compressed air or steam service! Pressure rating is based on the seal of the mating part. Pressure rating recommendations are based on the use of mating Dixon® fittings at ambient temperature 70°F (21°C) with a standard seal installed. NOT recommended for use with PTFE gaskets, polypropylene cam & groove should not be mixed with metal fittings.

Glass-Filled Polypropylene Part Number	Coupler x Hose Shank	Max. Operating Pressure	Replacement Gasket Part Number	Replacement Key Rings Part Number	Replacement Safety Clip Part Number
PPC50	3/4" x 1/2"	125 PSI	75-G-EPR	R200SS	GSAFETYCLIP
PPC75	3/4"	125 PSI	75-G-EPR	R200SS	GSAFETYCLIP
PPC100	1"	125 PSI	100-G-EPR	R200SS	GSAFETYCLIP
PPC125	1-1/2" x 1-1/4"	100 PSI	125-G-EPR	R200SS	GSAFETYCLIP
PPC150	1-1/2"	100 PSI	150-G-EPR	R200SS	GSAFETYCLIP
PPC200	2"	100 PSI	200-G-EPR	R200SS	GSAFETYCLIP
PPC300	3"	60 PSI	300-G-EPR	R200SS	GSAFETYCLIP
PPC400*	4"	50 PSI	400-G-EPR	R200SS	GSAFETYCLIP

* 4" coupler has 4 handles.

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
