RDWBPST200EZ by Dixon Valve | EZ Boss-Lock Cam & Groove Coupler for Welding | 2" Coupler Butt Weld x Schedule 40 Pipe/Socket Weld to Nominal Tubing | 316 Stainless Steel

RDWBPST200EZ by Dixon Valve | EZ Boss-Lock Cam & Groove Coupler for Welding | 2" Coupler Butt Weld x Schedule 40 Pipe/Socket Weld to Nominal Tubing | 316 Stainless Steel

Save $12.07 Save $12.07
$169.84
$169.84 - $169.84
$169.84
$157.77
$157.77 - $157.77
$157.77

Dixon Valve
EZ Boss-Lock Cam & Groove Coupler for Welding | Coupler Butt Weld x Schedule 40 Pipe/Socket Weld to Nominal Tubing

Designed for use with liquids.
Specifications for Variant SKU: RDWBPST200EZ Dixon
Brand: EZ Boss-Lock
Shape (Orientation): Straight
Ends Configuration: 2in Weld End, 2in Weld End, Some Ends Match
Material(s): 316 Stainless Steel
Safety Notes:
  • Under no circumstances should cam and groove couplings be used for compressed air or steam service!
  • Final weld preparation, as with all weld fittings, is the responsibility of the welder.
  • Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70°F / 21°C with a standard seal installed. For use at elevated temperature or other unusual operating conditions, consult Dixon.
Specifications:
  • Produced to interchange with all product produced to Commercial Item Description A-A-59326D.
316 Stainless Steel
Part Number		 Size Bore Max. Operating Pressure
RDWBPST075EZ 3/4" 0.765" 250 PSI
RDWBPST100EZ 1" 1.015" 250 PSI
RDWBPST150EZ 1-1/2" 1.515" 250 PSI
RDWBPST200EZ 2" 2.015" 250 PSI
RDWBPST300EZ 3" 3.015" 125 PSI
RDWBPST400EZ 4" 4.015" 100 PSI
RDWBPST600EZ 6" 6.020" 75 PSI
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
