RDWSP075EZ by Dixon Valve | EZ Boss-Lock Cam & Groove Coupler for Welding | 3/4" Coupler Socket Weld x Schedule 40 Pipe | 316 Stainless Steel

RDWSP075EZ by Dixon Valve | EZ Boss-Lock Cam & Groove Coupler for Welding | 3/4" Coupler Socket Weld x Schedule 40 Pipe | 316 Stainless Steel

Save $99.28 Save $99.28
$248.20
$248.20 - $248.20
$248.20
$148.92
$148.92 - $148.92
$148.92

Dixon Valve
EZ Boss-Lock Cam & Groove Coupler for Welding | Coupler Socket Weld x Schedule 40 Pipe

Designed for use with liquids.
Specifications for Variant SKU: RDWSP075EZ Dixon
Brand: EZ Boss-Lock
Shape (Orientation): Straight
Ends Configuration: 3/4in Female Cam & Groove, 3/4in Weld End
Material(s): 316 Stainless Steel
Safety Notes:
  • Under no circumstances should cam and groove couplings be used for compressed air or steam service!
  • Final weld preparation, as with all weld fittings, is the responsibility of the welder.
  • Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70°F / 21°C with a standard seal installed. For use at elevated temperature or other unusual operating conditions, consult Dixon.
Specifications:
  • Produced to interchange with all product produced to Commercial Item Description A-A-59326D.
316 Stainless Steel
Part Number		 Size Bore Max. Operating Pressure
RDWSP075EZ 3/4" 1.065" 250 PSI
RDWSP100EZ 1" 1.330" 250 PSI
RDWSP150EZ 1-1/2" 1.915" 250 PSI
RDWSP200EZ 2" 2.390" 250 PSI
RDWSP300EZ 3" 3.530" 125 PSI
RDWSP400EZ 4" 4.530" 100 PSI
RDWSP600EZ 6" 6.655" 75 PSI
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
