S830X875X120CS Dixon Carbon Steel King Crimp Style Sleeve - 8" Hose ID - 8.30" Sleeve ID - Length: 8.75"

S830X875X120CS Dixon Valve Carbon Steel King Crimp Style Sleeve - 8" Hose ID - 8.30" Sleeve ID - Length: 8.75"

$0.00 - $0.00
$0.00
$0.00
$0.00 - $0.00
$0.00

Dixon Boss LPS (Low Pressure Systems) - King Crimp™ Style Sleeves - Carbon Steel

Specifications for Variant SKU: S830X875X120CS Dixon
Shape (Orientation): No Orientation
Material(s): Carbon Steel
Applications:
  • Recommended for low-pressure discharge and suction service for compatible liquids.
Notes:
  • Only use the crimp style shanks with the crimp style sleeves and ferrules. Due to differences in dimensions and tolerances for safety reasons, do not interchange other manufacturer's products with Dixon products.
Part Number Hose ID Sleeve ID Sleeve Wall Thickness Sleeve Overall Length Weight (Lbs.)
S830X875X120CS 8" 8.30" 0.120" 8.75" N/A
S838X600X120CS 8" 8.38" 0.120" 6.00" 5.3000 lbs
S850X650X120CS 8" 8.50" 0.120" 6.50" 5.8500 lbs
S875X600X120CS 8" 8.75" 0.120" 6.00" 5.6000 lbs
S898X875X120CS 8" 8.98" 0.120" 8.75" N/A
S900X400X090CS 8" 9.00" 0.090" 4.00" N/A
S900X400X120CS 8" 9.00" 0.120" 4.00" 3.5000 lbs
S900X600X120CS 8" 9.00" 0.120" 6.00" 6.0000 lbs
S910X400X120CS 8" 9.10" 0.120" 4.00" N/A
S912X600X120CS 8" 9.12" 0.120" 6.00" 5.7500 lbs
S915X600X120CS 8" 9.15" 0.120" 6.00" N/A
S925X600X120CS 8" 9.25" 0.120" 6.00" 5.8600 lbs
S925X400X120CS 8" 9.25" 0.120" 4.00" 3.8000 lbs
S950X400X120CS 8" 9.50" 0.120" 4.00" N/A
S950X600X120CS 8" 9.50" 0.120" 6.00" 5.8500 lbs
S975X600X120CS 8" 9.75" 0.120" 6.00" 6.2000 lbs
S1025X750X120CS 10" 10.25" 0.120" 7.50" N/A
S1050X750X120CS 10" 10.50" 0.120" 7.50" 9.0000 lbs
S1100X600X120CS 10" 11.00" 0.120" 6.00" 7.0000 lbs
S1175X600X120CS 10" 11.75" 0.120" 6.00" 7.4000 lbs
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
