SW40-250200 by Dixon Valve | Threaded Concentric Reducer Nipple | Schedule 40 | 2-1/2" Male NPT x 2" Male NPT | 7" Length | Zinc Plated

Save $4.80

$43.21

$43.21 - $43.21

$43.21

$38.41

$38.41 - $38.41

$38.41

Dixon Valve
Threaded Concentric Nipple | Male NPT x Male NPT | Schedule 40

Quantity

Specifications for Variant SKU: SW40-250200 Dixon
Series:	SW40 Series
Shape (Orientation):	Straight
Ends Configuration:	2-1/2in Male NPT, 2in Male NPT
Material(s):	Zink-Plated Steel

Features:
Schedule 40 nipples have blue caps.
Approvals:
Manufactured in conformance with ASTM A234 and MSS SP-95 Threads on nipples conform to ASME B1.20.1

Zinc-Plated Part Number	Male NPT	Length
SW40-200100	2" x 1"	6.5"
SW40-200125	2" x 1-1/4"	6.5"
SW40-200150	2" x 1-1/2"	6.5"
SW40-250150	2-1/2" x 1-1/2"	7"
SW40-250200	2-1/2" x 2"	7"
SW40-300200	3" x 2"	8"
SW40-300250	3" x 2-1/2"	8"
SW40-400200	4" x 2"	9"
SW40-400250	4" x 2-1/2"	9"
SW40-400300	4" x 3"	9"
SW40-600300	6" x 3"	12"
SW40-600400	6" x 4"	12"
SW40-800400	8" x 4"	13"
SW40-800600	8" x 6"	13"

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
