V3-BRKIT by Dixon Valve | Hydraulic Quick Disconnect Coupling | V-Series | MIL-C-51234 Repair Kit | For 3/8" Body Size | Nitrile Seal | For Brass Plugs

V3-BRKIT by Dixon Valve | Hydraulic Quick Disconnect Coupling | V-Series | MIL-C-51234 Repair Kit | For 3/8" Body Size | Nitrile Seal | For Brass Plugs

Save $4.18 Save $4.18
$10.45
$10.45 - $10.45
$10.45
$6.27
$6.27 - $6.27
$6.27

Dixon Valve & Coupling
Hydraulic Coupling: V-Series MIL-C-51234 Plug Repair Kit

Repair Kit Contents (for one Plug): valve assembly and adapter O-ring.
Specifications for Variant SKU: V3-BRKIT Dixon
Series: V-Series
Seal Material(s): Buna-N/Nitrile Rubber
Compatibility & Interchange:
  • Interchangeable to MIL-C-51234
  • Snap-Tite H/IH and Faster TNV/TNL
Additional Information:
Part Number Fits Body Size Coupler Material Seal Material Seal Kit Contents
V2-RKIT 1/4" Steel Nitrile Steel valve assembly and adapter O-ring
V2-BRKIT 1/4" Brass Nitrile Brass valve assembly and adapter O-ring
V2-SSRKIT 1/4" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

V3-RKIT 3/8" Steel Nitrile Steel valve assembly and adapter O-ring
V3-BRKIT 3/8" Brass Nitrile Brass valve assembly and adapter O-ring
V3-SSRKIT 3/8" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

V4-RKIT 1/2" Steel Nitrile Steel valve assembly and adapter O-ring
V4-BRKIT 1/2" Brass Nitrile Brass valve assembly and adapter O-ring
V4-SSRKIT 1/2" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

V6-RKIT 3/4" Steel Nitrile Steel valve assembly and adapter O-ring
V6-BRKIT 3/4" Brass Nitrile Brass valve assembly and adapter O-ring
V6-SSRKIT 3/4" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

V8-RKIT 1" Steel Nitrile Steel valve assembly and adapter O-ring
V8-BRKIT 1" Brass Nitrile Brass valve assembly and adapter O-ring
V8-SSRKIT 1" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

140030-10 1-1/4" Steel Nitrile Steel valve assembly and adapter O-ring
140032-10 1-1/4" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

140030-12 1-1/2" Steel Nitrile Steel valve assembly and adapter O-ring
140032-12 1-1/2" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

140030-16 2" Steel Nitrile Steel valve assembly and adapter O-ring
140032-16 2" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring
