V591P-4-04 by Parker | Ball Valves | 1/4" Male Pipe Thread | 15/16" Hex | 5.52" Length | 90° Elbow | Brass

Save $11.84

$48.49

$48.49 - $48.49

$48.49

$36.65

$36.65 - $36.65

$36.65

by Parker Hannifin
Ball Valves Brass Series 590/591:Lever Handle, 90° Flow, Male-Male Pipe Ends V591P-X-04

Specifications for Variant SKU: V591P-4-04 Parker
Series:	V591P Series
Shape (Orientation):	90° Elbow
Material(s):	Brass, Chrome-Plated Brass, Steel
Seal Material(s):	PTFE
Special Properties:	Valved

Specification:
Product Features:	Forged brass body Chrome plated brass ball PTFE seats/seals Steel handle
Style:	V-Valve
Type:	590-Male/Female 591-Male/Female
Material:	P-Brass
Options:	04-Lever Handle 08-Unmarked yellow vinyl handle cover
Temperature Range:	-50° to +350° F (-45.5° to +176.6° C)
Pressure Range:	250 PSI (17.2 bar) Saturated Steam up to 150 PSI (10.3 bar) Vacuum Service to 29 Inches Hg


Part Number	Straight Thread	Hex	H	K	L	M	N	Flow Diameter (D)
V591P-4-04	1/4"	15/16"	3.96"	1.08"	5.52"	1.56"	3.02"	.375"
V591P-6-04	3/8"	15/16"	3.96"	1.09"	5.52"	1.56"	3.03"	.375"
V591P-8-04	1/2"	1-1/16"	3.80"	1.30"	5.64"	1.84"	2.95"	.500"
