W171PLP-2-2 by Parker | Prestolok PLP Push-to-Connect Fittings | Threaded Fitting | 1/8" Swivel Push-to-Connect x 1/8" Swivel Push-to-Connect x 1/8" Male NPTF Thread | 7/16" Hex | Tee | Nickel-Plated Brass | Pack of 10

W171PLP-2-2 by Parker | Prestolok PLP Push-to-Connect Fittings | Threaded Fitting | 1/8" Swivel Push-to-Connect x 1/8" Swivel Push-to-Connect x 1/8" Male NPTF Thread | 7/16" Hex | Tee | Nickel-Plated Brass | Pack of 10

Save $80.37 Save $80.37
$200.93
$200.93 - $200.93
$200.93
$120.56
$120.56 - $120.56
$120.56

by Parker Hannifin
Push-to-Connect Fittings:W171PLP Male Run Tee Swivel – NPTF

Package Quantity: 10 Units

Specifications for Variant SKU: W171PLP-2-2 Parker | 10 |
Series: W171PLP Series
Shape (Orientation): Tee
Material(s): Nickel-Plated Brass, Stainless Steel, PVDF
Seal Material(s): Buna-N/Nitrile Rubber
Special Properties: Corrosion Resistance, Flame Resistant Release Button, Swivel
Product Features:
  • Stainless steel grab ring
  • Nickel-plated brass body
  • Nitrile seal
  • Flame resistant release button
  • Corrosion resistance
  • Inch and metric tube connections
  • NPT, BSPP, BSPT, and metric threads
  • Meets UL94 V-0 Flame Resistance Standard
Markets:
  • Industrial
  • Automotive
  • Climate Control
  • Welding
  • Robotic Welding
Compatible Media:
  • Compressed Air
  • Inert Gases
  • Vacuum
Pressure Range: Up to 300 PSI (20.6 bar) depending on tubing
Temperature Range: 0° to +200° F (-17.7° to 93.3° C)
Vacuum Rating: 28" Hg
Compatible Tubing:
  • 95FR Microweld
  • Polyethylene
  • Polypropylene
  • Semi Rigid Nylon
  • Rigid Nylon
  • Polyurethane 95 Durometer Shore A
Part Number Tube Size Pipe Thread NPTF Hex (C) L N Flow Diameter (D)
W171PLP-2-2 1/8" 1/8" 7/16" .74" .92" .094"
W171PLP-5/32-2 5/32" 1/8" 7/16" .77" .92" .125"
W171PLP-4-2 1/4" 1/8" 7/16" .85" .92" .156"
W171PLP-4-4 1/4" 1/4" 9/16" .85" 1.10" .156"
W171PLP-4-6 1/4" 3/8" 11/16" .85" 1.24" .156"
W171PLP-5-2 5/16" 1/8" 9/16" .97" 1.02" .250"
W171PLP-5-4 5/16" 1/4" 9/16" .97" 1.24" .250"
W171PLP-6-4 3/8" 1/4" 9/16" 1.01" 1.24" .250"
W171PLP-6-6 3/8" 3/8" 11/16" 1.01" 1.24" .250"
W171PLP-8-6 1/2" 3/8" 11/16" 1.15" 1.31" .312"
W171PLP-8-8 1/2" 1/2" 7/8" 1.15" .1.52" .312"
