FBVG125 by Dixon Valve | Global Ball Valve | Full Port | 1-1/4" Female NPT x 1-1/4" Female NPT | Forged Brass

Name: FBVG125 by Dixon Valve | Global Ball Valve | Full Port | 1-1/4" Female NPT x 1-1/4" Female NPT | Forged Brass
Brand: Dixon
SKU: FBVG125 Dixon
Price: 25.92 USD
Availability: InStock

Save $17.28

$43.20

$43.20 - $43.20

$43.20

$25.92

$25.92 - $25.92

$25.92

Dixon Valve & Coupling
Global Ball Valve | Forged Brass

For water and air only.

Quantity

Specifications for Variant SKU: FBVG125 Dixon
Shape (Orientation):	Straight
Ends Configuration:	1-1/4in Female NPT, 1-1/4in Female NPT, Some Ends Match
Material(s):	Forged Brass

Materials:
Body: Forged Brass
Specifications:
Pressure ratings: - 1/4" - 3/8" rated to 365 PSI - 1/2" - 2" rated to 600 PSI Maximum temperature: 248°F (120°C)

Part Number	Female NPT x Female NPT	Port
FBVG25	1/4"	Full
FBVG38	3/8"	Full
FBVG50	1/2"	Full
FBVG75	3/4"	Full
FBVG100	1"	Full
FBVG125	1-1/4"	Full
FBVG150	1-1/2"	Full
FBVG200	2"	Full

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
