HEPS-5X6 by Campbell Fittings | Expander | 1-1/4" Male NPT Thread x 1-1/2" Hose Barb | Plated Steel

HEPS-5X6 by Campbell Fittings | Expander | 1-1/4" Male NPT Thread x 1-1/2" Hose Barb | Plated Steel

Save $7.44 Save $7.44
$19.96
$19.96 - $19.96
$19.96
$12.52
$12.52 - $12.52
$12.52

by Campbell
Combination Nipples & Menders:HEPS Expander Nipple
Specifications for Variant SKU: HEPS-5X6 Campbell Fittings
Series: HEPS Series
Shape (Orientation): Straight
Ends Configuration: 1-1/4in Male NPT, 1-1/2in Hose Barb
Material(s): Plated Steel
Recommended Use:
  • Liquid, bulk handling, low pressure air
Recommended Hose Attachments:
  • Sleeves
  • Preformed Bands Clamps
Features and Benefits:
  • Maximum number of serrations for maximum holding power
  • Long lead serration for easier hose insertion
  • Formed hex wrench area on 3/4" through 1-1/2" combination nipples for easier installation
Part Number Hose Size
HEPS-2X3 1/2" x 3/4"
HEPS-3X4 3/4" x 1"
HEPS-4X5 1" x 1-1/4"
HEPS-5X6 1-1/4" x 1-1/2"
HEPS-5X8 1-1/4" x 2"
HEPS-6X8 1-1/2" x 2"
HEPS-8X10 2" x 2-1/2"
HEPS-10X12 2-1/2" x 3"
HEPS-12X16 3" x 4"

Campbell Fittings

Campbell Fittings offers a range of hose fittings, couplings, ferrules, and sleeves, for applications across a variety of industries.
