KZ-20DY0-CF1 KZ Valve by Banjo | ACTUATOR ONLY for RAVEN Anhydrous Ammonia (NH3) Actuated Valves | EH2 Actuator Series | For Valve Size: 1" - 1-1/2" | Control Type: FAST RATE

Name: KZ-20DY0-CF1 KZ Valve by Banjo | ACTUATOR ONLY for RAVEN Anhydrous Ammonia (NH3) Actuated Valves | EH2 Actuator Series | For Valve Size: 1" - 1-1/2" | Control Type: FAST RATE
Brand: Banjo
SKU: KZ-20DY0-CF1 Banjo
Price: 365.69 USD
Availability: InStock

Save $45.71

$411.40

$411.40 - $411.40

$411.40

$365.69

$365.69 - $365.69

$365.69

Banjo® Liquid Handling Products
KZ Valve | ACTUATOR ONLY for Raven Anhydrous Ammonia (NH3) Actuated Valves

Quantity

Specifications for Variant SKU: KZ-20DY0-CF1 Banjo
Brand:	KZ Valve
Series:	EH2 Actuator Series

Part Number	Actuator Series	Control Type	For Valve Brand	For Valve Sizes	Cycle Time	Retrofit Actuator Mounting Kit Required
KZ-20DY0-CF1*	EH2	Fast Rate	Raven	1 - 1 1/2"	1.5 SEC	KZ-KRKIT For 1" & 1 1/4" Raven Valves KZ-KR15KIT For 1-1/2" Raven Valves
KZ-10DY0-CF1*	EH2	ON/OFF	Raven	1 - 1 1/2"	1.5 SEC	KZ-KRKIT For 1" & 1 1/4" Raven Valves KZ-KR15KIT For 1-1/2" Raven Valves
KZ-K0HU0-CF1*	EH2	Standard Rate	Raven	1 - 1 1/2"	8.0 SEC	KZ-KRKIT For 1" & 1 1/4" Raven Valves KZ-KR15KIT For 1-1/2" Raven Valves
KZ-20E8S-C01	EH9	Fast Rate	KZValve	Up To 1"	1.5 SEC	-
KZ-1CE9S-D01	EH9	ON/OFF	KZValve	Up To 1"	0.7 SEC	-
KZ-20E7S-D01	EH9	Standard Rate	KZValve	Up To 1"	3 SEC	-
KZ-20E8S-D01	EH9	Fast Rate	KZValve	Up To 1"	1.7 SEC	-
KZ-1AE9S-C01	EH9	ON/OFF	KZValve	Up To 1"	0.7 SEC	-

* These actuators are designed to replace Raven actuators on Raven valves. They require a retrofit actuator mounting kit.

Banjo

Banjo is a world-class producer of a wide range of mechanical and electrical valves, fittings, and self-priming centrifugal pumps for agriculture and numerous industrial applications that ship to every corner of the globe. Banjo employs an array of molding presses, numerous machining and assembly cells, and an optimized logistics system empowering our production and shipping operations.
