SW40-300200 by Dixon Valve | Threaded Concentric Reducer Nipple | Schedule 40 | 3" Male NPT x 2" Male NPT | 8" Length | Zinc Plated

SW40-300200 by Dixon Valve | Threaded Concentric Reducer Nipple | Schedule 40 | 3" Male NPT x 2" Male NPT | 8" Length | Zinc Plated

Save $7.63 Save $7.63
$68.70
$68.70 - $68.70
$68.70
$61.07
$61.07 - $61.07
$61.07

Dixon Valve
Threaded Concentric Nipple | Male NPT x Male NPT | Schedule 40
Specifications for Variant SKU: SW40-300200 Dixon
Series: SW40 Series
Shape (Orientation): Straight
Ends Configuration: 3in Male NPT, 2in Male NPT
Material(s): Zink-Plated Steel
Features:
  • Schedule 40 nipples have blue caps.
Approvals:
  • Manufactured in conformance with ASTM A234 and MSS SP-95
  • Threads on nipples conform to ASME B1.20.1
Zinc-Plated
Part Number		 Male NPT Length
SW40-200100 2" x 1" 6.5"
SW40-200125 2" x 1-1/4" 6.5"
SW40-200150 2" x 1-1/2" 6.5"
SW40-250150 2-1/2" x 1-1/2" 7"
SW40-250200 2-1/2" x 2" 7"
SW40-300200 3" x 2" 8"
SW40-300250 3" x 2-1/2" 8"
SW40-400200 4" x 2" 9"
SW40-400250 4" x 2-1/2" 9"
SW40-400300 4" x 3" 9"
SW40-600300 6" x 3" 12"
SW40-600400 6" x 4" 12"
SW40-800400 8" x 4" 13"
SW40-800600 8" x 6" 13"
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
