TCR-T16-24 by Dixon Valve | True I.D. PTFE Hose Fitting | Sanitary Tri-Clamp | 1" Hose Size x 1-1/2" Clamp Size | 316 Stainless Steel

TCR-T16-24 by Dixon Valve | True I.D. PTFE Hose Fitting | Sanitary Tri-Clamp | 1" Hose Size x 1-1/2" Clamp Size | 316 Stainless Steel

Save $8.92 Save $8.92
$100.45
$100.45 - $100.45
$100.45
$91.53
$91.53 - $91.53
$91.53

Dixon Valve
True I.D. PTFE Hose Fitting | Sanitary Tri-Clamp

Suitable for conveying acids, chemicals, foods and pharmaceuticals.

Crimp collars for all True ID fittings are sold separately.
Specifications for Variant SKU: TCR-T16-24 Dixon
Series: TCR-T Series
Shape (Orientation): Straight
Ends Configuration: 1in Hose Barb, 1-1/2in Sanitary Clamp End
Material(s): 316 Stainless Steel
Compatible with the following Series: WOC-T Series  |   BOC-T Series  |   WTB-T Series
Use:
  • For use with True I.D. PTFE hoses.
316 Stainless Steel
Part Number		 Hose Size Clamp Size Crimp Collars for Convoluted Hose Crimp Collars for Smooth Bore Hose
Carbon Steel 304 Stainless Steel Carbon Steel 304 Stainless Steel
TCR-T08-24 1/2" 1-1/2" CSC-T08-1 SSC-T08-1 CSC-T08-2 SSC-T08-2
TCR-T12-24 3/4" 1-1/2" CSC-T12-1 SSC-T12-1 CSC-T12-2 SSC-T12-2
TCR-T16-16 1" 1" CSC-T16-1 SSC-T16-1 CSC-T16-2 SSC-T16-2
TCR-T16-24 1" 1-1/2" CSC-T16-1 SSC-T16-1 CSC-T16-2 SSC-T16-2
TCR-T24-24 1-1/2" 1-1/2" CSC-T24-1 SSC-T24-1 CSC-T24-2 -
TCR-T32-32 2" 2" CSC-T32-1 SSC-T32-1 - -
