V6-BRKIT by Dixon Valve | Hydraulic Quick Disconnect Coupling | V-Series | MIL-C-51234 Repair Kit | For 3/4" Body Size | Nitrile Seal | For Brass Plugs

Save $13.22

$33.05

$33.05 - $33.05

$33.05

$19.83

$19.83 - $19.83

$19.83

Dixon Valve & Coupling
Hydraulic Coupling: V-Series MIL-C-51234 Plug Repair Kit

Repair Kit Contents (for one Plug): valve assembly and adapter O-ring.

Specifications for Variant SKU: V6-BRKIT Dixon
Series:	V-Series
Seal Material(s):	Buna-N/Nitrile Rubber

Compatibility & Interchange:	Interchangeable to MIL-C-51234 Snap-Tite H/IH and Faster TNV/TNL
Additional Information:	For a selection guide, cross reference tables, safety info, fluid compatibility, and other general info, please see: Dixon Valve Quick Disconnect Guide.PDF

Part Number	Fits Body Size	Coupler Material	Seal Material	Seal Kit Contents
V2-RKIT	1/4"	Steel	Nitrile	Steel valve assembly and adapter O-ring
V2-BRKIT	1/4"	Brass	Nitrile	Brass valve assembly and adapter O-ring
V2-SSRKIT	1/4"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

V3-RKIT	3/8"	Steel	Nitrile	Steel valve assembly and adapter O-ring
V3-BRKIT	3/8"	Brass	Nitrile	Brass valve assembly and adapter O-ring
V3-SSRKIT	3/8"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

V4-RKIT	1/2"	Steel	Nitrile	Steel valve assembly and adapter O-ring
V4-BRKIT	1/2"	Brass	Nitrile	Brass valve assembly and adapter O-ring
V4-SSRKIT	1/2"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

V6-RKIT	3/4"	Steel	Nitrile	Steel valve assembly and adapter O-ring
V6-BRKIT	3/4"	Brass	Nitrile	Brass valve assembly and adapter O-ring
V6-SSRKIT	3/4"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

V8-RKIT	1"	Steel	Nitrile	Steel valve assembly and adapter O-ring
V8-BRKIT	1"	Brass	Nitrile	Brass valve assembly and adapter O-ring
V8-SSRKIT	1"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

140030-10	1-1/4"	Steel	Nitrile	Steel valve assembly and adapter O-ring
140032-10	1-1/4"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

140030-12	1-1/2"	Steel	Nitrile	Steel valve assembly and adapter O-ring
140032-12	1-1/2"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

140030-16	2"	Steel	Nitrile	Steel valve assembly and adapter O-ring
140032-16	2"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
