1-1/2X2 3284H by Couplamatic | Hydraulic Return Line Hose | Two Fiber Braid | Red | 1-1/2" ID | 300ft

Save $209.33

$4,493.33

$4,493.33 - $4,493.33

$4,493.33

$4,284.00

$4,284.00 - $4,284.00

$4,284.00

Couplamatic Inc
Two Fiber Braid - 3284H Hydraulic Return Line Hose

Package Quantity: 300 FT

Quantity

Specifications for Variant SKU: 1-1/2X2 3284H Couplamatic \| 300 \|
Series:	Hydraulic Return Line Hose Series
Hose Color(s):	Red
Dash Size:	-24
Internal Diameter:	1.50in
Compatible with the following Series:	Suction & Return Line Coupling Series

Applications:	Hydraulic Return Line	SAE Rating:	N/A
Cover:	Rubber (Red)	Reinforcement:	Two Fiber Braid
Temperature:	-40F to +200F (-40 to +96C)

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/2X2 3284H	1/2"	0.875"	300 lbs.	-	7.5"	24 lbs.	500ft
3/4X2 3284H	3/4"	1.156"	300 lbs.	-	11.5"	41 lbs.	500ft
1X2 3284H	1"	1.437"	300 lbs.	-	14"	62 lbs.	450ft
1-1/4X2 3284H	1-1/4"	1.781"	250 lbs.	-	18.5"	84 lbs.	400ft
1-1/2X2 3284H	1-1/2"	2.031"	250 lbs.	-	22"	104 lbs.	300ft

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
