1X2 3284H by Couplamatic | Hydraulic Return Line Hose | Two Fiber Braid | Red | 1" ID | 450ft

1X2 3284H by Couplamatic | Hydraulic Return Line Hose | Two Fiber Braid | Red | 1" ID | 450ft

$2,466.67 - $2,466.67
$2,466.67
$2,520.00
$2,520.00 - $2,520.00
$2,520.00

Couplamatic Inc
Two Fiber Braid - 3284H Hydraulic Return Line Hose


Package Quantity: 450 FT

Specifications for Variant SKU: 1X2 3284H Couplamatic | 450 |
Series: Hydraulic Return Line Hose Series
Hose Color(s): Red
Dash Size: -16
Internal Diameter: 1in
Compatible with the following Series: Suction & Return Line Coupling Series
Applications: Hydraulic Return Line SAE Rating: N/A
Cover: Rubber (Red) Reinforcement: Two Fiber Braid
Temperature: -40F to +200F (-40 to +96C)
Part Number Hose ID Hose OD Working Pressure
(lbs)		 Min. Burst Pressure
(lbs)		 Min. Bend Radius Weight per 100ft Reel Footage
1/2X2 3284H 1/2" 0.875" 300 lbs. - 7.5" 24 lbs. 500ft
3/4X2 3284H 3/4" 1.156" 300 lbs. - 11.5" 41 lbs. 500ft
1X2 3284H 1" 1.437" 300 lbs. - 14" 62 lbs. 450ft
1-1/4X2 3284H 1-1/4" 1.781" 250 lbs. - 18.5" 84 lbs. 400ft
1-1/2X2 3284H 1-1/2" 2.031" 250 lbs. - 22" 104 lbs. 300ft
Couplamatic Systems Inc

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
