1" 2SK Couplamatic Import Thin Cover 2-Wire Extreme Pressure Hydraulic Hose (Exceeds 2SN/2SC) - 1" ID - 200ft

1" 2SK by Couplamatic | Import Thin Cover | 2-Wire Extreme Pressure Hydraulic Hose | Exceeds 2SN/2SC | 1" ID | 200ft

Save $802.13

$2,005.33

$2,005.33 - $2,005.33

$2,005.33

$1,203.20

$1,203.20 - $1,203.20

$1,203.20

Couplamatic Systems Inc.
Two Wire Braid Hoses - 2SN Import Thin Cover 2-Wire Hydraulic Hose - SAE 100R2AT/2SN

Package Quantity: 200 FT

Specifications for Variant SKU: 1" 2SK Couplamatic \| 200 \|
Series:	2SK Series
Hose Color(s):	Black
Dash Size:	-16
Internal Diameter:	1in
Outer Diameter:	1.41in
Applicable Specs & Approvals:	Applicable MSHA Standards
Compatible with the following Series:	A Series \| Grip Crimp Series

Exceeds 2SN/2SC — Two Wire

2SK Import Thin Cover Two Wire Extreme Pressure Hydraulic Hose

Two-wire thin cover hose whose working pressures exceed both 2SN and 2SC ratings — extra pressure margin without going to a spiral hose.

1

What is this hose used for?

High Pressure Hydraulics
Industrial
Agricultural

2

What are the key specifications?

Rating

Exceeds 2SN/2SC

Cover

Abrasion and Flame Resistant Cover, MSHA Approved

Reinforcement

Two Wire Braids

Temperature

-40°F to +212°F (-40°C to +100°C)

3

What are the main product features?

Exceeds 2SN and 2SC ratings — more working pressure than standard two wire hose.
Thin cover construction — compact outside diameters for tight routing.
Two wire braids — extreme pressure hydraulic service.
MSHA approved cover — abrasion and flame resistant.

4

Which sizes are available?

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/4" 2SK	1/4"	0.520"	6,530 lbs.	26,120 lbs.	2.0"	24 lbs.	500ft
3/8" 2SK	3/8"	0.687"	5,585 lbs.	22,340 lbs.	3.0"	34 lbs.	400ft
1/2" 2SK	1/2"	0.810"	5,000 lbs.	20,000 lbs.	3.6"	43 lbs.	300ft
5/8" 2SK	5/8"	0.980"	4,625 lbs.	18,500 lbs.	4.0"	51 lbs.	250ft
3/4" 2SK	3/4"	1.155"	4,350 lbs.	17,400 lbs.	5.0"	61 lbs.	250ft
1" 2SK	1"	1.410"	3,250 lbs.	13,000 lbs.	6.5"	94 lbs.	200ft
1-1/4" 2SK	1-1/4"	1.715"	2,500 lbs.	10,000 lbs.	12.0"	130 lbs.	Bulk

i

Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.
