1A8KF8 Aeroquip by Danfoss | 1 & 2 Wire TTC Komatsu Female Swivel (KF) Crimp Fitting | -08 Female Komatsu Swivel x -08 Hose Barb | Steel
1A8KF8 Aeroquip by Danfoss | 1 & 2 Wire TTC Komatsu Female Swivel (KF) Crimp Fitting | -08 Female Komatsu Swivel x -08 Hose Barb | Steel
1A8KF8 Aeroquip by Danfoss | 1 & 2 Wire TTC Komatsu Female Swivel (KF) Crimp Fitting | -08 Female Komatsu Swivel x -08 Hose Barb | Steel
1A8KF8 Aeroquip by Danfoss | 1 & 2 Wire TTC Komatsu Female Swivel (KF) Crimp Fitting | -08 Female Komatsu Swivel x -08 Hose Barb | Steel

1A8KF8 Aeroquip by Danfoss | 1 & 2 Wire TTC Komatsu Female Swivel (KF) Crimp Fitting | -08 Female Komatsu Swivel x -08 Hose Barb | Steel

$26.33 - $26.33
$26.33
$26.33 - $26.33
$26.33

Aeroquip® by Danfoss
1 & 2 Wire TTC Female Komatsu Swivel Crimp Fitting (KF) - Straight

(Formerly Eaton Aeroquip)
Specifications for Variant SKU: 1A8KF8 Danfoss
Shape (Orientation): Straight
Ends Configuration: 1/2in Female Komatsu, 1/2in Hose Barb
Material(s): Steel
Special Properties: Swivel
Compatible with the following Series: 2661 Series  |   FC310 Series  |   FC510 Series  |   FC579 Series  |   FC611 Series  |   FC619 Series  |   FC639 Series  |   FC839B Series  |   FC693 Series  |   FC735 Series  |   FC849 Series  |   FC849B Series  |   GH120 Series  |   GH194 Series  |   GH195 Series  |   GH663 Series  |   GH681 Series  |   GH781 Series  |   GH793 Series
Technical Info:
Steel
Part Number 		Thread Hose Size A D E&Oslash Hex 1

 Hex 2
1A4KF4 M14 x 1.5 -04 2.21" 1.29" 1.66" 0.75" 0.75"
1A6KF6 M18 x 1.5 -06 2.38" 1.38" 0.26" 0.94" 0.87"
1A8KF8 M22 x 1.5 -08 2.64" 1.57" 0.38" 1.06" 1.06"
1A10KF10 M24 x 1.5 -10 2.84" 1.81" 0.49" 1.19" 1.18"
1A10KF12 M24 x 1.5 -12 3.01" 1.83" 0.49" 1.26" 1.18"
1A12KF12 M30 x 1.5 -12 3.21" 2.02" 0.61" 1.42" 1.42"
1A16KF16 M33 x 1.5 -16 3.60" 2.24" 0.81" 1.61" 1.61"
1A20KF20 M36 x 1.5 -20 4.46" 2.73" 1.05" 1.81" 1.81"
