203008-8-8S Aeroquip by Danfoss | 37° JIC Flare Bulkhead Run/37° JIC Flare Tee Adapter | -08 Male 37° JIC Flare Bulkhead x -08 Male 37° JIC Flare x -08 Male 37° JIC Flare | Steel

203008-8-8S Aeroquip by Danfoss | 37° JIC Flare Bulkhead Run/37° JIC Flare Tee Adapter | -08 Male 37° JIC Flare Bulkhead x -08 Male 37° JIC Flare x -08 Male 37° JIC Flare | Steel

Name: 203008-8-8S Aeroquip by Danfoss | 37° JIC Flare Bulkhead Run/37° JIC Flare Tee Adapter | -08 Male 37° JIC Flare Bulkhead x -08 Male 37° JIC Flare x -08 Male 37° JIC Flare | Steel
Brand: Danfoss/Eaton
SKU: 203008-8-8S Danfoss
Price: 14.35 USD
Availability: InStock

$14.35 - $14.35

$14.35

$14.35 - $14.35

$14.35

Aeroquip® by Danfoss
Male 37° JIC Flare Bulkhead Run/37° JIC Flare Tee Adapter
Male 37° JIC Flare Bulkhead x Male 37° JIC Flare x Male 37° JIC Flare

(Formerly Eaton Aeroquip)

Quantity

Specifications for Variant SKU: 203008-8-8S Danfoss
Shape (Orientation):	Tee
Ends Configuration:	1/2in Male JIC, 1/2in Male JIC, 1/2in Male JIC
Material(s):	Steel

Specifications:
Ref. SAE 070958


Part Number Steel	Tube O.D.	Thread T	A	B	C
203008-3-3S	0.19"	3/8-24	1.50"	0.94"	0.94"
203008-6-6S	0.38"	9/16-18	1.81	1.09"	1.09"
203008-8-8S	0.50"	3/4-16	2.11	1.36"	1.36"
203008-12-12S	0.75"	1-1/16-12	2.67"	1.78"	1.78"
203008-16-16S	1.00"	1-5/16-12	2.80"	1.94"	1.94"
203008-20-20S	1.25"	1-5/8-12	3.12"	2.17"	2.17"
