2V-BRKIT by Dixon Valve | Hydraulic Quick Disconnect Coupling | V-Series | MIL-C-51234 Repair Kit | For 1/4" Body Size | Nitrile Seal | For Brass Couplers

2V-BRKIT by Dixon Valve | Hydraulic Quick Disconnect Coupling | V-Series | MIL-C-51234 Repair Kit | For 1/4" Body Size | Nitrile Seal | For Brass Couplers

Save $0.32 Save $0.32
$7.64
$7.64 - $7.64
$7.64
$7.32
$7.32 - $7.32
$7.32

Dixon Valve & Coupling
Hydraulic Coupling: V-Series MIL-C-51234 Coupler Repair Kit

Repair Kit Contents (for one coupler): valve assembly and adapter O-ring.
Specifications for Variant SKU: 2V-BRKIT Dixon
Series: V-Series
Seal Material(s): Buna-N/Nitrile Rubber
Compatibility & Interchange:
  • Interchangeable to MIL-C-51234
  • Snap-Tite H/IH and Faster TNV/TNL
Additional Information:
Part Number Fits Body Size Coupler Material Seal Material Seal Kit Contents
2V-RKIT 1/4" Steel Nitrile Steel valve assembly and adapter O-ring
2V-BRKIT 1/4" Brass Nitrile Brass valve assembly and adapter O-ring
2V-SSRKIT 1/4" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

3V-RKIT 3/8" Steel Nitrile Steel valve assembly and adapter O-ring
3V-BRKIT 3/8" Brass Nitrile Brass valve assembly and adapter O-ring
3V-SSRKIT 3/8" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

4V-RKIT 1/2" Steel Nitrile Steel valve assembly and adapter O-ring
4V-BRKIT 1/2" Brass Nitrile Brass valve assembly and adapter O-ring
4V-SSRKIT 1/2" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

6V-RKIT 3/4" Steel Nitrile Steel valve assembly and adapter O-ring
6V-BRKIT 3/4" Brass Nitrile Brass valve assembly and adapter O-ring
6V-SSRKIT 3/4" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

8V-RKIT 1" Steel Nitrile Steel valve assembly and adapter O-ring
8V-BRKIT 1" Brass Nitrile Brass valve assembly and adapter O-ring
8V-SSRKIT 1" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

140030-10 1-1/4" Steel Nitrile Steel valve assembly and adapter O-ring
140032-10 1-1/4" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

140030-12 1-1/2" Steel Nitrile Steel valve assembly and adapter O-ring
140032-12 1-1/2" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

140030-16 2" Steel Nitrile Steel valve assembly and adapter O-ring
140032-16 2" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring
