6V-RKIT by Dixon Valve | Hydraulic Quick Disconnect Coupling | V-Series | MIL-C-51234 Repair Kit | For 3/4" Body Size | Nitrile Seal | For Steel Couplers

Save $0.54

$13.22

$13.22 - $13.22

$13.22

$12.68

$12.68 - $12.68

$12.68

Dixon Valve & Coupling
Hydraulic Coupling: V-Series MIL-C-51234 Coupler Repair Kit

Repair Kit Contents (for one coupler): valve assembly and adapter O-ring.

Quantity

Specifications for Variant SKU: 6V-RKIT Dixon
Series:	V-Series
Seal Material(s):	Buna-N/Nitrile Rubber

Compatibility & Interchange:	Interchangeable to MIL-C-51234 Snap-Tite H/IH and Faster TNV/TNL
Additional Information:	For a selection guide, cross reference tables, safety info, fluid compatibility, and other general info, please see: Dixon Valve Quick Disconnect Guide.PDF

Part Number	Fits Body Size	Coupler Material	Seal Material	Seal Kit Contents
2V-RKIT	1/4"	Steel	Nitrile	Steel valve assembly and adapter O-ring
2V-BRKIT	1/4"	Brass	Nitrile	Brass valve assembly and adapter O-ring
2V-SSRKIT	1/4"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

3V-RKIT	3/8"	Steel	Nitrile	Steel valve assembly and adapter O-ring
3V-BRKIT	3/8"	Brass	Nitrile	Brass valve assembly and adapter O-ring
3V-SSRKIT	3/8"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

4V-RKIT	1/2"	Steel	Nitrile	Steel valve assembly and adapter O-ring
4V-BRKIT	1/2"	Brass	Nitrile	Brass valve assembly and adapter O-ring
4V-SSRKIT	1/2"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

6V-RKIT	3/4"	Steel	Nitrile	Steel valve assembly and adapter O-ring
6V-BRKIT	3/4"	Brass	Nitrile	Brass valve assembly and adapter O-ring
6V-SSRKIT	3/4"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

8V-RKIT	1"	Steel	Nitrile	Steel valve assembly and adapter O-ring
8V-BRKIT	1"	Brass	Nitrile	Brass valve assembly and adapter O-ring
8V-SSRKIT	1"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

140030-10	1-1/4"	Steel	Nitrile	Steel valve assembly and adapter O-ring
140032-10	1-1/4"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

140030-12	1-1/2"	Steel	Nitrile	Steel valve assembly and adapter O-ring
140032-12	1-1/2"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring

140030-16	2"	Steel	Nitrile	Steel valve assembly and adapter O-ring
140032-16	2"	316 Stainless	Nitrile	316 SS valve assembly and adapter O-ring
