3/4" CS-FLEX 5 Couplamatic Four Spiral High Pressure Import Hydraulic Hose (SAE 100R12) - 3/4" ID - Bulk

3/4" CS-FLEX 5 by Couplamatic | Four Spiral High Pressure Import Hydraulic Hose | SAE 100R12 | 3/4" ID | 50ft Bulk Length

Save $250.45

$626.12

$626.12 - $626.12

$626.12

$375.67

$375.67 - $375.67

$375.67

Couplamatic Systems Inc.
4 High Tensile Steel Spirals - CS-FLEX 5 Four Spiral High Pressure Import Hydraulic Hose - (SAE 100R12)

Specifications for Variant SKU: 3/4" CS-FLEX 5 Couplamatic \| 50 \|
Series:	CS-FLEX 5 Series
Hose Color(s):	Black
Dash Size:	-12
Internal Diameter:	0.75in
Outer Diameter:	1.20in
Applicable Specs & Approvals:	Applicable MSHA Standards, SAE 100R12
Compatible with the following Series:	GW Series \| 4GC Series

Exceeds SAE 100R12 — Four Spiral

CS-Flex 5 Four Spiral High Pressure Hydraulic Hose

A four-spiral hose that meets and exceeds SAE 100R12, combining higher working pressures with a reduced bend radius.

1

What is this hose used for?

High Pressure Hydraulics
Industrial
Agricultural

2

What are the key specifications?

SAE Rating

Meets and Exceeds SAE 100R12

Cover

Abrasion and Flame Resistant Black Cover, MSHA Approved

Reinforcement

4 High Tensile Steel Spirals

Temperature

-40°F to +250°F (-40°C to +121°C)

3

What are the main product features?

Exceeds SAE 100R12 — higher working pressures than the standard specification.
Reduced bend radius — easier routing in confined equipment envelopes.
Four high tensile steel spirals — high pressure, high impulse service.
MSHA approved cover — abrasion and flame resistant black cover.

4

Which sizes are available?

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Coil Footage
1/2" CS-FLEX 5	1/2"	0.950"	5,500 lbs.	22,000 lbs.	3.5"	57 lbs.	Bulk
3/4" CS-FLEX-5	3/4"	1.200"	5,500 lbs.	22,000 lbs.	4.7"	96 lbs.	Bulk
1" CS-FLEX 5	1"	1.480"	5,000 lbs.	20,000 lbs.	7"	148 lbs.	Bulk
1-1/4" CS-FLEX 5	1-1/4"	1.810"	5,000 lbs.	20,000 lbs.	11"	173 lbs.	Bulk

i

Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
