3108 04 11 by Parker | LF3000® Push-to-Connect Fittings | 5/32" Push-to-Connect x 5/32" Push-to-Connect x 1/8" Male NPT Thread | 1.10" Length | Tee | Nylon

3108 04 11 by Parker | LF3000® Push-to-Connect Fittings | 5/32" Push-to-Connect x 5/32" Push-to-Connect x 1/8" Male NPT Thread | 1.10" Length | Tee | Nylon | Pack of 10

Save $5.47 Save $5.47
$60.18
$60.18 - $60.18
$60.18
$54.71
$54.71 - $54.71
$54.71

by Parker Hannifin
LF 3000® Push-In Fittings / Stud Fittings:3108 - male branch tee fractional and metric inch tube to male NPT or UNF to tube

Package Quantity: 10 Units

Specifications for Variant SKU: 3108 04 11 Parker | 10 |
Brand: LF 3000®
Series: 3108 Series
Shape (Orientation): Tee
Material(s): Nylon, Nickel-Plated Brass, Stainless Steel
Seal Material(s): Buna-N/Nitrile Rubber
Product Features:
  • Stainless steel grab ring
  • Glass-reinforced nylon 6.6 body
  • Nitrile D-seal
  • Nylon release button
  • Corrosion and chemical resistance
  • Silicone-Free
Markets:
  • Pneumatic
  • Industrial
  • Automation
  • Robotic
  • Printing
  • Packaging
  • Textile
Applications:
  • Air
  • Cutting Fluids
  • Inert Gases
  • Vacuum
Pressure Range
  • Up to 290 psi (20 bar)
    3/16" diameter up to 260 psi (8 bar) Maximum working pressure and temperature range are dependent on the type of tubing used
Temperature Range
  • -4° to +175° F (-20° to +80° C)
    3/16" diameter 5° to +155° F (-15° to +68° C)
Vacuum Capability
  • 28" Hg
Part Number ØD NPT / UNF (C) F G H L Oz
3108 53 20 1/8" 10-32 8 mm .33" .61" .57" .23 Oz
3108 53 08 1/8" 1/16" 10 mm .33" .61" .57" .27 Oz
3108 53 11 1/8" 1/8" 11 mm .33" .61" .57" .33 Oz
3108 53 14 1/8" 1/4" 14 mm .33" .63" .57" .66 Oz
3108 04 20 5/32" 10-32 8 mm .33" .71" .55" .18 Oz
3108 04 11 5/32" 1/8" 11 mm .33" .61" .55" .32 Oz
3108 04 14 6 mm 1/4" 14 mm .33" .63" .55" .65 Oz
3108 06 11 6 mm 1/8" 11 mm .43" .69" .63" .32 Oz
3108 06 14 6 mm 1/4" 14 mm .43" .71" .63" .60 Oz
3108 55 11* 3/16" 1/8" 11 mm .43" .67" .85" .64 Oz
3108 56 11 1/4" 1/8" 11 mm .43" .67" .71" .39 Oz
3108 56 14 1/4" 1/4" 14 mm .43" .63" .71" .56 Oz
3108 56 18 1/4" 3/8" 18 mm .43" .65" .71" .85 Oz
3108 08 11 5/16" 1/8" 11 mm .53" .87" .91" .49 Oz
3108 08 14 5/16" 1/4" 14 mm .53" .83" .91" .66 Oz
3108 08 18 5/16" 3/8" 18 mm .53" .85" .91" .97 Oz
3108 60 11 3/8" 1/8" 15 mm .63" .99" 1.04" .81 Oz
3108 60 14 3/8" 1/4" 15 mm .63" .99" 1.04" .88 Oz
3108 60 18 3/8" 3/8" 18 mm .63" .95" 1.04" 1.18 Oz
3108 60 22 3/8" 1/2" 22 mm .63" .98" 1.04" 1.86 Oz
3108 62 14 1/2" 1/4" 20 mm .87" 1.22" 1.38" 1.88 Oz
3108 62 18 1/2" 3/8" 20 mm .87" 1.22" 1.38" 1.93 Oz
3108 62 22 1/2" 1/2" 24 mm .87" 1.12" 1.38" 2.35 Oz
3108 10 14 10 mm 1/4" 15 mm .63" .98" 1.04" .74 Oz
3108 10 18 10 mm 3/8" 18 mm .63" .95" 1.04" .85 Oz
3108 10 22 10 mm 1/2" 22 mm .63" .98" 1.04" .99 Oz
3108 12 18 12 mm 3/8" 18 mm .87" 1.06" 1.22" 3.25 Oz
3108 12 22 12 mm 1/2" 22 mm .87" .98" 1.22" 3.84 Oz
