3108 08 18 by Parker | LF3000® Push-to-Connect Fittings | 5/16" Push-to-Connect x 5/16" Push-to-Connect x 3/8" Male NPT Thread | 1.82" Length | Tee | Nylon

3108 08 18 by Parker | LF3000® Push-to-Connect Fittings | 5/16" Push-to-Connect x 5/16" Push-to-Connect x 3/8" Male NPT Thread | 1.82" Length | Tee | Nylon | Pack of 10

Save $8.02 Save $8.02
$88.17
$88.17 - $88.17
$88.17
$80.15
$80.15 - $80.15
$80.15

by Parker Hannifin
LF 3000® Push-In Fittings / Stud Fittings:3108 - male branch tee fractional and metric inch tube to male NPT or UNF to tube

Package Quantity: 10 Units

Specifications for Variant SKU: 3108 08 18 Parker | 10 |
Brand: LF 3000®
Series: 3108 Series
Shape (Orientation): Tee
Material(s): Nylon, Nickel-Plated Brass, Stainless Steel
Seal Material(s): Buna-N/Nitrile Rubber
Product Features:
  • Stainless steel grab ring
  • Glass-reinforced nylon 6.6 body
  • Nitrile D-seal
  • Nylon release button
  • Corrosion and chemical resistance
  • Silicone-Free
Markets:
  • Pneumatic
  • Industrial
  • Automation
  • Robotic
  • Printing
  • Packaging
  • Textile
Applications:
  • Air
  • Cutting Fluids
  • Inert Gases
  • Vacuum
Pressure Range
  • Up to 290 psi (20 bar)
    3/16" diameter up to 260 psi (8 bar) Maximum working pressure and temperature range are dependent on the type of tubing used
Temperature Range
  • -4° to +175° F (-20° to +80° C)
    3/16" diameter 5° to +155° F (-15° to +68° C)
Vacuum Capability
  • 28" Hg
Part Number ØD NPT / UNF (C) F G H L Oz
3108 53 20 1/8" 10-32 8 mm .33" .61" .57" .23 Oz
3108 53 08 1/8" 1/16" 10 mm .33" .61" .57" .27 Oz
3108 53 11 1/8" 1/8" 11 mm .33" .61" .57" .33 Oz
3108 53 14 1/8" 1/4" 14 mm .33" .63" .57" .66 Oz
3108 04 20 5/32" 10-32 8 mm .33" .71" .55" .18 Oz
3108 04 11 5/32" 1/8" 11 mm .33" .61" .55" .32 Oz
3108 04 14 6 mm 1/4" 14 mm .33" .63" .55" .65 Oz
3108 06 11 6 mm 1/8" 11 mm .43" .69" .63" .32 Oz
3108 06 14 6 mm 1/4" 14 mm .43" .71" .63" .60 Oz
3108 55 11* 3/16" 1/8" 11 mm .43" .67" .85" .64 Oz
3108 56 11 1/4" 1/8" 11 mm .43" .67" .71" .39 Oz
3108 56 14 1/4" 1/4" 14 mm .43" .63" .71" .56 Oz
3108 56 18 1/4" 3/8" 18 mm .43" .65" .71" .85 Oz
3108 08 11 5/16" 1/8" 11 mm .53" .87" .91" .49 Oz
3108 08 14 5/16" 1/4" 14 mm .53" .83" .91" .66 Oz
3108 08 18 5/16" 3/8" 18 mm .53" .85" .91" .97 Oz
3108 60 11 3/8" 1/8" 15 mm .63" .99" 1.04" .81 Oz
3108 60 14 3/8" 1/4" 15 mm .63" .99" 1.04" .88 Oz
3108 60 18 3/8" 3/8" 18 mm .63" .95" 1.04" 1.18 Oz
3108 60 22 3/8" 1/2" 22 mm .63" .98" 1.04" 1.86 Oz
3108 62 14 1/2" 1/4" 20 mm .87" 1.22" 1.38" 1.88 Oz
3108 62 18 1/2" 3/8" 20 mm .87" 1.22" 1.38" 1.93 Oz
3108 62 22 1/2" 1/2" 24 mm .87" 1.12" 1.38" 2.35 Oz
3108 10 14 10 mm 1/4" 15 mm .63" .98" 1.04" .74 Oz
3108 10 18 10 mm 3/8" 18 mm .63" .95" 1.04" .85 Oz
3108 10 22 10 mm 1/2" 22 mm .63" .98" 1.04" .99 Oz
3108 12 18 12 mm 3/8" 18 mm .87" 1.06" 1.22" 3.25 Oz
3108 12 22 12 mm 1/2" 22 mm .87" .98" 1.22" 3.84 Oz
Parker Fluid System Connectors Division

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
