3330 55 03 by Parker | Legris Caps Manual Release Button | 3/16" Tube O.D. | Red | Cap | Pack of 100

Save $10.00

$39.33

$39.33 - $39.33

$39.33

$29.33

$29.33 - $29.33

$29.33

by Parker Hannifin
Push-to-Connect Fittings:3110 - 3330 Caps Manual Release Button - Inch

Package Quantity: 100 Units

Specifications for Variant SKU: 3330 55 03 Parker \| 100 \|
Series:	3330 Series
Shape (Orientation):	No Orientation
Material(s):	Polymer
Special Properties:	Corrosion Resistance, Chemical Resistance, Silicone Free

Installation:	Mark out the fixing hole Make hole in panel Simply push the fitting into place To complete the installation To identify circuits simply remove the black release button and replace with colored one

Tube O.D. (in)	Tube O.D. (mm)	White Part Number	Black Part Number	Green Part Number	Red Part Number	Blue Part Number	Yellow Part Number
1/8"	-	3110 53 00	-	3110 53 02	3110 53 03	3110 53 04	3110 53 05
5/32"	4 mm	-	3330 04 01	3110 04 02	3110 04 03	3110 04 04	3110 04 05
3/16"	-	3330 55 00	3330 55 01	3330 55 02	3330 55 03	3330 55 04	-
1/4"	-	3110 56 00	3330 56 01	3110 56 02	3110 56 03	3110 56 04	3110 56 05
5/16"	8 mm	3110 08 00	-	3110 08 02	3110 08 03	3110 08 04	3110 08 05
1/2"	-	3110 62 00	3330 62 01	3110 62 02	3110 62 03	3110 62 04	3110 62 05
