381303-6 by Alemite | Mist Fitting | Inlet: 1/8" Female NPTF | Outlet: 1/4" Male NPTF | Brass

381303-6 by Alemite | Mist Fitting | Inlet: 1/8" Female NPTF | Outlet: 1/4" Male NPTF | Brass

Save $0.41 Save $0.41
$38.62
$38.62 - $38.62
$38.62
$38.21
$38.21 - $38.21
$38.21

PRODUCT DESCRIPTION

Alemite Centralized Lubrication - Oil Mist - Mist Fittings
Specifications for Variant SKU: 381303-6 Alemite
Applications:
  • Alemite Oil Mist Systems are used to service all types of machine elements that require continuous lubrication, such as rolling element bearings and chain drives. Delivering a continuous, measured stream of clean atomized oil, Alemite Oil Mist Systems have no moving parts for long, reliable life. Alemite Oil Mist Systems use less lubricant, making them a very cost effective option for continuous, automatic lubrication.
Features:
  • NA

Part Number Inlet Outlet CFM @ 20" H2O
380791-2 1/8"NPTF(f) 1/8" PTF(m) SAE Special Short 0.08
380791-4 1/8"NPTF(f) 1/8" PTF(m) SAE Special Short 0.16
380791-6 1/8"NPTF(f) 1/8" PTF(m) SAE Special Short 0.24
380791-10 1/8"NPTF(f) 1/8" PTF(m) SAE Special Short 0.49
380791-16 1/8"NPTF(f) 1/8" PTF(m) SAE Special Short 0.68
381303-4 1/8"NPTF(f) 1/4"NPTF(m) 0.16
381303-6 1/8"NPTF(f) 1/4"NPTF(m) 0.24
381303-10 1/8"NPTF(f) 1/4"NPTF(m) 0.49
381303-16 1/8"NPTF(f) 1/4"NPTF(m) 0.68
381290-2 1/4" OD Tube ftg. 1/8" PTF(m) SAE Special Short 0.08
381290-4 1/4" OD Tube ftg. 1/8" PTF(m) SAE Special Short 0.16
381290-6 1/4" OD Tube ftg. 1/8" PTF(m) SAE Special Short 0.24
381290-10 1/4" OD Tube ftg. 1/8" PTF(m) SAE Special Short 0.49
381290-16 1/4" OD Tube ftg. 1/8" PTF(m) SAE Special Short 0.68
