3V-BRKIT by Dixon Valve | Hydraulic Quick Disconnect Coupling | V-Series | MIL-C-51234 Repair Kit | For 3/8" Body Size | Nitrile Seal | For Brass Couplers

3V-BRKIT by Dixon Valve | Hydraulic Quick Disconnect Coupling | V-Series | MIL-C-51234 Repair Kit | For 3/8" Body Size | Nitrile Seal | For Brass Couplers

Save $4.67 Save $4.67
$11.68
$11.68 - $11.68
$11.68
$7.01
$7.01 - $7.01
$7.01

Dixon Valve & Coupling
Hydraulic Coupling: V-Series MIL-C-51234 Coupler Repair Kit

Repair Kit Contents (for one coupler): valve assembly and adapter O-ring.
Specifications for Variant SKU: 3V-BRKIT Dixon
Series: V-Series
Seal Material(s): Buna-N/Nitrile Rubber
Compatibility & Interchange:
  • Interchangeable to MIL-C-51234
  • Snap-Tite H/IH and Faster TNV/TNL
Additional Information:
Part Number Fits Body Size Coupler Material Seal Material Seal Kit Contents
2V-RKIT 1/4" Steel Nitrile Steel valve assembly and adapter O-ring
2V-BRKIT 1/4" Brass Nitrile Brass valve assembly and adapter O-ring
2V-SSRKIT 1/4" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

3V-RKIT 3/8" Steel Nitrile Steel valve assembly and adapter O-ring
3V-BRKIT 3/8" Brass Nitrile Brass valve assembly and adapter O-ring
3V-SSRKIT 3/8" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

4V-RKIT 1/2" Steel Nitrile Steel valve assembly and adapter O-ring
4V-BRKIT 1/2" Brass Nitrile Brass valve assembly and adapter O-ring
4V-SSRKIT 1/2" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

6V-RKIT 3/4" Steel Nitrile Steel valve assembly and adapter O-ring
6V-BRKIT 3/4" Brass Nitrile Brass valve assembly and adapter O-ring
6V-SSRKIT 3/4" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

8V-RKIT 1" Steel Nitrile Steel valve assembly and adapter O-ring
8V-BRKIT 1" Brass Nitrile Brass valve assembly and adapter O-ring
8V-SSRKIT 1" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

140030-10 1-1/4" Steel Nitrile Steel valve assembly and adapter O-ring
140032-10 1-1/4" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

140030-12 1-1/2" Steel Nitrile Steel valve assembly and adapter O-ring
140032-12 1-1/2" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring

140030-16 2" Steel Nitrile Steel valve assembly and adapter O-ring
140032-16 2" 316 Stainless Nitrile 316 SS valve assembly and adapter O-ring
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
