5/8" 026H Couplamatic Textile Covered Push-on Hose - One Fiber Braid - 5/8" ID - 500ft

5/8" 026H by Couplamatic | Textile Covered Push-on Hose | One Fiber Braid | 5/8" ID | 500ft

Save $9.26

$1,992.59

$1,992.59 - $1,992.59

$1,992.59

$1,983.33

$1,983.33 - $1,983.33

$1,983.33

Couplamatic Systems Inc.
One Fiber Braid - 026H Textile Covered Push-on Hose

Package Quantity: 500 FT

Quantity

Specifications for Variant SKU: 5/8" 026H Couplamatic \| 500 \|
Series:	026H Series
Hose Color(s):	Black
Internal Diameter:	0.625in
Outer Diameter:	0.91in
Cover Construction:	Textile Braid

Applications:	Low Pressure	SAE Rating:	N/A
Cover:	Oil and Mildew Resistant Textile	Reinforcement:	One Fiber Braid
Temperature:	-40 to +200F (-40 to +96C)

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/4" 026H	1/4"	0.500"	300 lbs.	1,200 lbs.	2.5"	7 lbs.	500ft
3/8" 026H	3/8"	0.640"	300 lbs.	1,200 lbs.	3"	10 lbs.	500ft
1/2" 026H	1/2"	0.750"	300 lbs.	1,200 lbs.	5"	12 lbs.	500ft
5/8" 026H	5/8"	0.910"	300 lbs.	1,200 lbs.	6"	19 lbs.	500ft
3/4" 026H	3/4"	1.031"	300 lbs.	1,200 lbs.	7"	21 lbs.	500ft

*Cut lengths available. 100' minimum*
