60181020 (10X20B) by PT-Coupling | Reducing Cam & Groove Adapter | Type B | 1" Coupler x 2" Male NPT | Aluminum/HBS | Buna-N Seal

60181020 (10X20B) by PT-Coupling | Reducing Cam & Groove Adapter | Type B | 1" Coupler x 2" Male NPT | Aluminum/HBS | Buna-N Seal

Save $29.45 Save $29.45
$79.32
$79.32 - $79.32
$79.32
$49.87
$49.87 - $49.87
$49.87

PT Coupling
Reducing Cam & Groove (Camlock) Adapter | Type B | Adapter x Male NPT | Aluminum/HBS | Buna-N Seal

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA
Specifications for Variant SKU: 60181020 PT-Coupling
Shape (Orientation): Straight
Cam Type: Type B
Ends Configuration: 1in Female Cam & Groove, 2in Male NPT
Material(s): Aluminum
Seal Material(s): Buna-N/Nitrile
Features & Applications:
  • HBS cam arms are made of 300 series Stainless Steel.
  • Lightweight and economical. Good abrasion resistance. Fair corrosion and chemical resistance.
  • Use with water, hydraulic oil, coolants, gasoline, and petroleum products.
  • Made in the USA
Part
Name		 Item # Coupler
Size		 Male NPT
Threads		 Max. Allowable
Working Press.
(PSI)*
10X20B 60181020 1" 2" 200 PSI
15X10B 60181510 1-1/2" 1" 250 PSI
15X20B 60181520 1-1/2" 2" 250 PSI
20X15B 60182015 2" 1-1/2" 250 PSI
20X30B 60182030 2" 3" 200 PSI
25X20B 60182520 2-1/2" 2" 200 PSI
25X30B 60182530 2-1/2" 3" 200 PSI
30X20B 60183020 3" 2" 200 PSI
30X25B 60183025 3" 2-1/2" 200 PSI
30X40B 60183040 3" 4" 150 PSI
40X20B 60184020 4" 2" 150 PSI
40X30B 60184030 4" 3" 150 PSI

** Denotes parts are produced as a welded fabrication.
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
