60184030 (40X30B) by PT-Coupling | Reducing Cam & Groove Adapter | Type B | 4" Coupler x 3" Male NPT | Aluminum/HBS | Buna-N Seal

Save $53.83

$145.02

$145.02 - $145.02

$145.02

$91.19

$91.19 - $91.19

$91.19

PT Coupling
Reducing Cam & Groove (Camlock) Adapter | Type B | Adapter x Male NPT | Aluminum/HBS | Buna-N Seal

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA

Specifications for Variant SKU: 60184030 PT-Coupling
Shape (Orientation):	Straight
Cam Type:	Type B
Ends Configuration:	4in Female Cam & Groove, 3in Male NPT
Material(s):	Aluminum
Seal Material(s):	Buna-N/Nitrile

Features & Applications:
HBS cam arms are made of 300 series Stainless Steel. Lightweight and economical. Good abrasion resistance. Fair corrosion and chemical resistance. Use with water, hydraulic oil, coolants, gasoline, and petroleum products. Made in the USA

Part Name	Item #	Coupler Size	Male NPT Threads	Max. Allowable Working Press. (PSI)*
10X20B	60181020	1"	2"	200 PSI
15X10B	60181510	1-1/2"	1"	250 PSI
15X20B	60181520	1-1/2"	2"	250 PSI
20X15B	60182015	2"	1-1/2"	250 PSI
20X30B	60182030	2"	3"	200 PSI
25X20B	60182520	2-1/2"	2"	200 PSI
25X30B	60182530	2-1/2"	3"	200 PSI
30X20B	60183020	3"	2"	200 PSI
30X25B	60183025	3"	2-1/2"	200 PSI
30X40B	60183040	3"	4"	150 PSI
40X20B	60184020	4"	2"	150 PSI
40X30B	60184030	4"	3"	150 PSI

** Denotes parts are produced as a welded fabrication.
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
