GJF-2 by Campbell Fittings | Ground Joint Coupling | Female Set | with wing nut | 1/2" Female NPT Thread x 1/2" Hose Shank | Viton® Seal | Ductile Iron/Steel

GJF-2 by Campbell Fittings | Ground Joint Coupling | Female Set | with wing nut | 1/2" Female NPT Thread x 1/2" Hose Shank | Viton® Seal | Ductile Iron/Steel

Save $11.40 Save $11.40
$44.24
$44.24 - $44.24
$44.24
$32.84
$32.84 - $32.84
$32.84

by Campbell
VITON® Seal Ground Joint Couplings:Steel/Ductile Iron Female Set (with wing nut)
Specifications for Variant SKU: GJF-2 Campbell Fittings
Shape (Orientation): Straight
Ends Configuration: 1/2in Female NPT, 1/2in Hose Barb
Material(s): Ductile Iron, Steel
Seal Material(s): Viton
Recommended Use:
  • High-pressure steam and air
Recommended Hose Attachments:
  • Interlocking Ferrules
  • Interlocking U-bolt clamps
Features and Benefits:
  • Viton Seal Coupling pass 1000 hour MIL-H-29210 steam test.
  • Eliminates leaks with nut hand tightened.
  • Viton seal (formulated by DuPont for high pressure steam and air applications) is protected inside machined stem groove and by swivel nut, extending working life.
  • Spud does not contain plastic seat, extending working life.
  • Interchangeable with old-style domestic ground joint couplings.
  • Machined hose ends with smooth end detail to reduce potential failure due to abrasion - grips, seals, and protects hose.
  • Interlock groove locks ferrule into place for superior holding power.
Part Number Hose Size
GJF-2 1/2"
GJF-3 3/4"
GJF-4 1"
GJF-5 1-1/4"
GJF-6 1-1/2"
GJF-8 2"
GJF-10 2-1/2"
GJF-12 3"
GJF-16 4"
