HPBV125ZPL by Dixon Valve | High Pressure Ball Valve | 1-1/4" Female NPT x 1-1/4" Female NPT | Clear Zinc Coated Carbon Steel

HPBV125ZPL by Dixon Valve | High Pressure Ball Valve | 1-1/4" Female NPT x 1-1/4" Female NPT | Clear Zinc Coated Carbon Steel

Save $25.28 Save $25.28
$227.49
$227.49 - $227.49
$227.49
$202.21
$202.21 - $202.21
$202.21

Dixon Valve & Coupling
High Pressure Ball Valve | Clear Zinc Coated Carbon Steel

These valves are commonly found in industrial plants and are most commonly used for hydraulic oil applications. They can be used anywhere a carbon steel ball valve is required. The clear zinc coating makes this ideal for environments where standard black oxide carbon steel high-pressure ball valve is not enough.
Specifications for Variant SKU: HPBV125ZPL Dixon
Shape (Orientation): Straight
Ends Configuration: 1-1/4in Female NPT, 1-1/4in Female NPT, Some Ends Match
Material(s): Clear Zinc Coated Carbon Steel
Seal Material(s): Buna-N/Nitrile Rubber
Features:
  • 1/4" - 1" is a block body and full port.
  • 1-1/4" - 2" is a forged body and full port.
Materials:
  • Nitrile rubber O-rings.
  • POM (Polyacetal) ball seats.
  • Nickel plated ball.
  • Carbon steel body.
Specifications:
  • Temperature range: -20°F to 215°F (-28°C to 101°C)
  • 1/4" - 1/2" pressure rating: 7350 PSI
  • 3/4" - 2" pressure rating: 6000 PSI
Approvals:
  • RoHS compliant
Part Number Thread Type Size PSI
HPBV25ZPL Female NPT x Female NPT 1/4" 7350 PSI
HPBV38ZPL Female NPT x Female NPT 3/8" 7350 PSI
HPBV12ZPL Female NPT x Female NPT 1/2" 7350 PSI
HPBV34ZPL Female NPT x Female NPT 3/4" 6000 PSI
HPBV10ZPL Female NPT x Female NPT 1" 6000 PSI
HPBV125ZPL Female NPT x Female NPT 1-1/4" 6000 PSI
HPBV150ZPL Female NPT x Female NPT 1-1/2" 6000 PSI
HPBV200ZPL Female NPT x Female NPT 2" 6000 PSI

HPBV25SAEZPL Female SAE ORB x Female SAE ORB 1/4" 7350 PSI
HPBV38SAEZPL Female SAE ORB x Female SAE ORB 3/8" 7350 PSI
HPBV12SAEZPL Female SAE ORB x Female SAE ORB 1/2" 7350 PSI
HPBV34SAEZPL Female SAE ORB x Female SAE ORB 3/4" 6000 PSI
HPBV10SAEZPL Female SAE ORB x Female SAE ORB 1" 6000 PSI
HPBV125SAEZPL Female SAE ORB x Female SAE ORB 1-1/4" 6000 PSI
HPBV150SAEZPL Female SAE ORB x Female SAE ORB 1-1/2" 6000 PSI
HPBV200SAEZPL Female SAE ORB x Female SAE ORB 2" 6000 PSI
