MC3092 by Dixon Valve | Type B (Bauer Style) Quick Connect Fitting | 2" Size | Male with Hose Barb | Galvanized Steel

MC3092 by Dixon Valve | Type B (Bauer Style) Quick Connect Fitting | 2" Size | Male with Hose Barb | Galvanized Steel

Save $17.25 Save $17.25
$43.13
$43.13 - $43.13
$43.13
$25.88
$25.88 - $25.88
$25.88

Dixon Valve
Type B (Bauer Style) Quick Connect Fitting | Male with Hose Barb

Used primarily on irrigation and suction lines.
Specifications for Variant SKU: MC3092 Dixon
Shape (Orientation): Straight
Ends Configuration: 2in Male Bauer - Type B, 2in Hose Barb
Material(s): Galvanized Steel
Features:
  • Bauer style locks on the male side.
  • Has a double pin locking lever for smooth closing action.
  • Gasket included on female half.
  • Each coupler is equipped with a safety pin to prevent accidental openings.
Materials:
  • Hot dipped, galvanized
Safety Notes:
  • These fittings are not recommended for chemicals or any hazardous type materials where the possibility of leakage would result in health or environmental concerns.
Type B (Bauer-Lock) | Male with Hose Barb
Part Number Description
MC3092 2"
MC3093 3"
MC3094 4"
MC3096 6"
MC3098 8"
MC30910* 10"
MC30912* 12"

*10" and 12" supplied with ACB304 lever assist bar

Type B (Bauer-Lock) | Female with Hose Barb
Part Number Size
FC3102 2"
FC3103 3"
FC3104 4"
FC3106 6"
FC3108 8"
FC31010 10"
FC31012 12"
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
