PUSH-10-250 by Texcel | TEX-PUSH-ON 300 Series | Push-On Hose | 5/8" Hose ID | 300 PSI | Gray | 250ft Length

PUSH-10-250 by Texcel | TEX-PUSH-ON 300 Series | Push-On Hose | 5/8" Hose ID | 300 PSI | Gray | 250ft Length

Save $227.20 Save $227.20
$795.20
$795.20 - $795.20
$795.20
$568.00
$568.00 - $568.00
$568.00

Texcel
TEX-PUSH-ON 300 Series | 300psi Push-On Hose

Package Quantity: 250 Units

Specifications for Variant SKU: PUSH-10-250-GRAY Texcel | 250 |
Series: TEX-PUSH-ON 300 Series
Hose Color(s): Gray
Internal Diameter: 0.625in
Outer Diameter: 0.94in
Tubing Construction: Nitrile
Cover Construction: Nitrile/PVC Blend
Technical Data:
Description: Low pressure braided hose for quick and easy insertion of push-on fittings with no special crimping tools required. Its internal polyester reinforcement design allows for excellent coupling retention. Tube handles oil-laden air, lubricating oils, mild alkalis or caustic solutions, fuel oil, and other petroleumbased products. Tube: Black, NBR (ARPM Class A)
Cover: Black, Red, Blue NBR/PVC (ARPM Class A) Reinforcement: Reinforced braided polyester cords
Safety Factor: 4:1 Temperature: -40°F to +212°F (-40°C to +100°C)
Branding: TEXCEL® TEX-PUSH-ON Packaging: 1pc Reel
Part Number Dash Hose ID (Inch) Hose ID (Dn) Hose OD (Inch) Hose OD (mm) Working Pressure (psi) Burst Pressure (psi) Weight (lbs/ft)
PUSH-4-250 4 1/4" 6 1/2" 13 300 1200 0.10 lbs
PUSH-6-250 6 3/8" 10 33/50" 17 300 1200 0.14 lbs
PUSH-8-250 8 1/2" 12 81/100" 21 300 1200 0.19 lbs
PUSH-10-250 10 5/8" 16 47/50" 24 300 1200 0.22 lbs
PUSH-12-250 12 3/4" 19 1-9/100" 28 300 1200 0.28 lbs
PUSH-16-250 16 1" 25 1-2/5" 35.5 250 1000 0.46 lbs
PUSH-4-250-BLACK 4 1/4" 6 1/2" 13 300 1200 0.10 lbs
PUSH-6-250-BLACK 6 3/8" 10 33/50" 17 300 1200 0.14 lbs
PUSH-8-250-BLACK 8 1/2" 12 81/100" 21 300 1200 0.19 lbs
PUSH-10-250-BLACK 10 5/8" 16 47/50" 24 300 1200 0.22 lbs
PUSH-12-250-BLACK 12 3/4" 19 1-9/100" 28 300 1200 0.28 lbs
PUSH-16-250-BLACK 16 1" 25 1-2/5" 35.5 250 1000 0.46 lbs
PUSH-4-250-RED 4 1/4" 6 1/2" 13 300 1200 0.10 lbs
PUSH-6-250-RED 6 3/8" 10 33/50" 17 300 1200 0.14 lbs
PUSH-8-250-RED 8 1/2" 12 81/100" 21 300 1200 0.19 lbs
PUSH-10-250-RED 10 5/8" 16 47/50" 24 300 1200 0.22 lbs
PUSH-12-250-RED 12 3/4" 19 1-9/100" 28 300 1200 0.28 lbs
PUSH-16-250-RED 16 1" 25 1-2/5" 35.5 250 1000 0.46 lbs
PUSH-4-250-BLUE 4 1/4" 6 1/2" 13 300 1200 0.10 lbs
PUSH-6-250-BLUE 6 3/8" 10 33/50" 17 300 1200 0.14 lbs
PUSH-8-250-BLUE 8 1/2" 12 81/100" 21 300 1200 0.19 lbs
PUSH-10-250-BLUE 10 5/8" 16 47/50" 24 300 1200 0.22 lbs
PUSH-12-250-BLUE 12 3/4" 19 1-9/100" 28 300 1200 0.28 lbs
PUSH-16-250-BLUE 16 1" 25 1-2/5" 35.5 250 1000 0.46 lbs
