SBC500SSFL by Dixon Valve | MannTek Safety Break-Away Coupling | Industrial Version | 5" Size | 125 DN | 150# Flange x 150# Flange | 316 Stainless Steel
SBC500SSFL by Dixon Valve | MannTek Safety Break-Away Coupling | Industrial Version | 5" Size | 125 DN | 150# Flange x 150# Flange | 316 Stainless Steel
SBC500SSFL by Dixon Valve | MannTek Safety Break-Away Coupling | Industrial Version | 5" Size | 125 DN | 150# Flange x 150# Flange | 316 Stainless Steel

SBC500SSFL by Dixon Valve | MannTek Safety Break-Away Coupling | Industrial Version | 5" Size | 125 DN | 150# Flange x 150# Flange | 316 Stainless Steel

$0.00 - $0.00
$0.00
$0.00
$0.00 - $0.00
$0.00

Dixon Valve
MannTek Safety Break-Away Coupling | Industrial Version | 150# Flange x 150# Flange

Coupling is designed to minimize spillage and damage associated with drive away and pull away incidents.

Typical applications: Loading rack.
Specifications for Variant SKU: SBC500SSFL Dixon
Brand: MannTek
Shape (Orientation): Straight
Ends Configuration: 5in 150# Flange, 5in 150# Flange, Some Ends Match
Material(s): 316 Stainless Steel
Seal Material(s): Viton/FKM
Features:
  • Designed to be installed between a fixed point (pipe, pump, manifold) and a hose.
  • Coupling automatically senses an excessive load, closes the valves and disconnects.
  • High flow rate / low pressure drop.
Construction:
  • FKM (FPM) seal standard.
Specifications:
  • Working pressure:
    • Stainless Steel: 360 PSI at ambient temperature 70°F (21°C)
    • Aluminum: 230 PSI at ambient temperature 70°F (21°C)
How It Works:
  • The safety breakaway valve consists of two halves, each with a valve that has an O-ring seal. When the safety breakaway couplings separate, it allows the valves to close. The two valves close rapidly, minimizing exposure to personnel and the environment.
  • Safety breakaway couplings have three external break bolts. In the case of axial tension all of the bolts take up the force corresponding to the break force on the hose with a safety margin. Non-axial forces concentrate the tension forces more strongly on one bolt, so that the safety breakaway coupling reacts in a natural way to the reduction of the hose break forces.
316 Stainless Steel
Part Number		 Aluminum
Part Number		 Size DN Size Length Width Flow
SBC100SSFL - 1" 25 DN 5" (120 mm) 4.3" (108 mm) -
SBC200SSFL SBC200ALFL 2" 50 DN 7" (178 mm) 4.5" (114 mm) 200 GPM (757 LPM)
SBC300SSFL SBC300ALFL 3" 80 DN 8.5" (216 mm) 6.8" (173 mm) 650 GPM (2460 LPM)
SBC400SSFL SBC400ALFL 4" 100 DN 9" (229 mm) 9.3" (236 mm) 800 GPM (3028 LPM)
SBC500SSFL SBC500ALFL 5" 125 DN 14" (356 mm) 10.6" (269 mm) 1100 GPM (4154 LPM)
SBC600SSFL SBC600ALFL 6" 150 DN 15.1" (384 mm) 12.5" (318 mm) 1500 GPM (5678 LPM)
SBC800SSFL - 8" 200 DN 17.7" (450 mm) 13.5" (343 mm) 3700 GPM (14000 LPM)
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
