SSCVIL125 by Dixon Valve | Check Valve | 800 PSI | 1-1/4" Female NPT x 1-1/4" Female NPT | 316 Stainless Steel

SSCVIL125 by Dixon Valve | Check Valve | 800 PSI | 1-1/4" Female NPT x 1-1/4" Female NPT | 316 Stainless Steel

Save $155.57 Save $155.57
$388.92
$388.92 - $388.92
$388.92
$233.35
$233.35 - $233.35
$233.35

Dixon Valve & Coupling
Check Valve | 800 PSI
Specifications for Variant SKU: SSCVIL125 Dixon
Shape (Orientation): Straight
Ends Configuration: 1-1/4in Female NPT, 1-1/4in Female NPT, Some Ends Match
Material(s): 316 Stainless Steel
Features:
  • Soft PTFE seat is spring loaded for fast seating action.
  • Flow profile designed to minimize head loss.
  • Corrosion resistance, excellent for use on chemicals.
  • Dual guided stem and disc.
Specifications:
  • Temperature range: 10°F to 450°F (-12°C to 232°C)
  • Pressure rating: 800 PSI WOG; 125 PSI saturated steam
  • Cracking pressure: .5 PSI
Part Number Female NPT x Female NPT
SSCVIL025 1/4" x 1/4"
SSCVIL038 3/8" x 3/8"
SSCVIL050 1/2" x 1/2"
SSCVIL075 3/4" x 3/4"
SSCVIL100 1" x 1"
SSCVIL125 1-1/4" x 1-1/4"
SSCVIL150 1-1/2" x 1-1/2"
SSCVIL200 2" x 2"
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
