V500P-32 by Parker | Ball Valves | 2" Female NPT Pipe Thread | 8.58" Length | Straight | Brass | Pack of 2

Save $178.37

$445.92

$445.92 - $445.92

$445.92

$267.55

$267.55 - $267.55

$267.55

by Parker Hannifin
Ball Valves Brass Series 500:Female-Female Pipe Ends V500P-20, V500P-24, V500P-32

Package Quantity: 2 Units

Specifications for Variant SKU: V500P-32 Parker \| 2 \|
Series:	V500P Series
Shape (Orientation):	Straight
Material(s):	Brass, Chrome-Plated Brass, Steel
Seal Material(s):	PTFE
Special Properties:	Valved

Specification:
Product Features:	Forged brass body Chrome plated brass ball PTFE seats/seals Steel handle
Style:	V-Valve VP-Valve, padlocking handle VV-Valve, vented VVP-Valve, vented, padlocking handle
Type:	500-Female/Female PTF ports
Material:	P-Brass PN-Nickel plated
Options:	01-Stainless Steel Ball & Stem 02-Stainless Steel Handle & Nut 03-Stainless Steel Ball, Stem, Handle & Nut 04-Tee Handle 08-Unmarked yellow vinyl handle cover 21-Oval Handle
Temperature Range:	0° to +350° F (-17.7° to +176.6° C)
Pressure Range:	600 WOG , Cold Non-shock Saturated Steam up to 150 PSI (10.3 bar) Vacuum Service to 29 Inches Hg Vented up to 250 PSI (17.2 bar)


Part Number	Pipe Thread (NPT)	Octagon	H	L	M	N	Flow Diameter (D)
V500P-20	1-1/4"	1.93"	6.22"	8.05"	3.66"	3.01"	1.18"
V500P-24	1-1/2"	2.13"	6.22"	8.23"	4.02"	3.25"	1.50"
V500P-32	2"	2.69"	6.22"	8.58"	4.76"	3.52"	1.89"

*PTF Special Short. **PTF SPL Extra Short
