V502SS-6-SUB by Parker | Rotary Actuator | 3/8" Size x 10-24 Female PNC Port | 15/16" Hex (H) | 2.07" Length | Straight | Brass

Save $2.64

$72.56

$72.56 - $72.56

$72.56

$69.92

$69.92 - $69.92

$69.92

by Parker Hannifin
Ball Valves Rotary Actuator Series Act:Actuator Sub-Assembly V502SS-X-SUB

Quantity

Specifications for Variant SKU: V502SS-6-SUB Parker
Series:	V502SS Series
Shape (Orientation):	Straight
Material(s):	Stainless Steel
Seal Material(s):	PTFE
Special Properties:	Abrasion Resistance

Specification:
Product Features:	One Piece Aluminum Extrusion Body PTFE Seals Stainless Steel Shaft Self Lubricated Vane Seal Anodized Aluminum Extrusion Vane
Temperature Range:	-40° to +180° F (-40° to +82.2° C)
Pressure Range:	Up to 250 PSI (17.2 bar) Vacuum service 28 inches Hg


Part Number	Size	A UNC	B	C	D	E	F	G	Hex (H)	J	K
V502SS-4-SUB	1/4"	10-24	1.88"	1.32"	.63"	2.07"	.50"	1.12"	15/16"	1.10"	1/4"-18 NPT
V502SS-6-SUB	3/8"	10-24	1.88"	1.32"	.63"	2.07"	.50"	1.12"	15/16"	1.10"	3/8"-18 NPT
V502SS-8-SUB	1/2"	10-24	2.00"	1.35"	.66"	2.27"	.50"	1.12"	1-1/16"	1.28"	1/2"-14 NPT

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
