V502SS-8-SUB by Parker | Rotary Actuator | 1/2" Size x 10-24 Female PNC Port | 1-1/16" Hex (H) | 2.20" Length | Straight | Brass

Save $2.63

$72.15

$72.15 - $72.15

$72.15

$69.52

$69.52 - $69.52

$69.52

by Parker Hannifin
Ball Valves Rotary Actuator Series Act:Actuator Sub-Assembly V502SS-X-SUB

Quantity

Specifications for Variant SKU: V502SS-8-SUB Parker
Series:	V502SS Series
Shape (Orientation):	Straight
Material(s):	Stainless Steel
Seal Material(s):	PTFE
Special Properties:	Abrasion Resistance

Specification:
Product Features:	One Piece Aluminum Extrusion Body PTFE Seals Stainless Steel Shaft Self Lubricated Vane Seal Anodized Aluminum Extrusion Vane
Temperature Range:	-40° to +180° F (-40° to +82.2° C)
Pressure Range:	Up to 250 PSI (17.2 bar) Vacuum service 28 inches Hg


Part Number	Size	A UNC	B	C	D	E	F	G	Hex (H)	J	K
V502SS-4-SUB	1/4"	10-24	1.88"	1.32"	.63"	2.07"	.50"	1.12"	15/16"	1.10"	1/4"-18 NPT
V502SS-6-SUB	3/8"	10-24	1.88"	1.32"	.63"	2.07"	.50"	1.12"	15/16"	1.10"	3/8"-18 NPT
V502SS-8-SUB	1/2"	10-24	2.00"	1.35"	.66"	2.27"	.50"	1.12"	1-1/16"	1.28"	1/2"-14 NPT
