1-13/16" HTR5 Couplamatic -32 Textile Covered One Wire High Temperature Hydraulic Hose (SAE 100R5) (SAE J1402, DOT FMVSS 106) - 1-13/16" ID - Bulk

1-13/16" HTR5 by Couplamatic | -32 Textile Covered | One Wire High Temperature Hydraulic Hose | SAE 100R5 | SAE J1402 | 1-13/16" ID | 50ft Bulk Length

Save $710.22 Save $710.22
$1,775.55
$1,775.55 - $1,775.55
$1,775.55
$1,065.33
$1,065.33 - $1,065.33
$1,065.33

Couplamatic Systems Inc.
One Wire Braid - HTR5 High Temperature Textile Covered Hydraulic Hose - (SAE 100R5) - (SAE J1402, DOT FMVSS 106 AII)
Specifications for Variant SKU: 1-13/16" HTR5 Couplamatic | 50 |
Series: HTR5 Series
Hose Color(s): Blue
Dash Size: -32
Internal Diameter: 1.8125in
Outer Diameter: 2.22in
Cover Construction: Textile Braid
Applicable Specs & Approvals: SAE 100R5, SAE J1402
Compatible with the following Series: R5 Series  |   Reusable Couplings Series
SAE 100R5 — High Temperature, Textile Cover

HTR5 Textile Covered High Temperature Hydraulic Hose

One wire braid SAE 100R5 hose under a blue high temperature textile braid cover, rated to +300°F and DOT approved through 5/8" for air brake service.

1

What is this hose used for?
  • Medium Pressure High Temp Hydraulics
  • Air
  • Water.
2

What are the key specifications?
SAE Rating

SAE 100R5, SAE J1402, DOT FMVSS 106 AII (3/16" thru 5/8")

Cover

Blue Textile Braid, High Temperature

Reinforcement

One Wire Braid

Temperature

-40°F to +300°F (-40°C to +150°C)

3

What are the main product features?
  • +300°F service temperature — well above standard hydraulic hose ratings.
  • SAE J1402 / DOT FMVSS 106 AII — approved for air brake service in 3/16" through 5/8".
  • Blue textile braid cover — the traditional 100R5 construction, easy to identify.
  • Hydraulics, air and water — a genuinely multi-service hose.
  • Wide size range — 3/16" (-4) through 1-13/16" (-32).
4

Which sizes are available?
Part Number Hose ID Hose OD Working Pressure
(lbs)		 Min. Burst Pressure
(lbs)		 Min. Bend Radius Weight per 100ft Reel Footage
3/16" HTR5 3/16"(-04) 0.520" 3,000 lbs. 12,000 lbs. 3" 15 lbs. 250ft
1/4" HTR5 1/4"(-05) 0.580" 3,000 lbs. 12,000 lbs. 3.4" 17 lbs. 250ft
5/16" HTR5 5/16"(-06) 0.680" 2,250 lbs. 9,000 lbs. 4" 22 lbs. 250ft
13/32" HTR5 13/32"(-08) 0.770" 2,000 lbs. 8,000 lbs. 4.6" 30 lbs. 250ft
1/2" HTR5 1/2"(-10) 0.921" 1,750 lbs. 7,000 lbs. 5.5" 37 lbs. 250ft
5/8" HTR5 5/8"(-12) 1.080" 1,500 lbs. 6,000 lbs. 6.5" 46 lbs. 250ft
7/8" HTR5 7/8"(-16) 1.240" 800 lbs. 3,200 lbs. 7.4" 48 lbs. 250ft
1-1/8" HTR5 1-1/8"(-20) 1.500" 625 lbs. 2,500 lbs. 9" 52 lbs. 100ft
1-3/8" HTR5 1-3/8"(-24) 1.750" 500 lbs. 2,000 lbs. 10.5" 81 lbs. Bulk
1-13/16" HTR5 1-13/16"(-32) 2.220" 350 lbs. 1,400 lbs. 13.2" 99 lbs. Bulk
i
Cut lengths are available. Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.
