FF9855-16 Aeroquip by Danfoss | -10 Low Temperature Buna-N (Nitrile) O-Ring for SAE O-Ring Face Seal Fittings (ORS)

Name: FF9855-16 Aeroquip by Danfoss | -10 Low Temperature Buna-N (Nitrile) O-Ring for SAE O-Ring Face Seal Fittings (ORS)
Brand: Danfoss/Eaton
SKU: FF9855-16 Danfoss
Price: 0.65 USD
Availability: InStock

$0.65 - $0.65

$0.65

$0.65 - $0.65

$0.65

Aeroquip® by Danfoss
O-Ring for SAE O-Ring Face Seal Fittings (ORS)

(Formerly Eaton Aeroquip)

Quantity

Specifications for Variant SKU: FF9855-16 Danfoss
Shape (Orientation):	No Orientation
Seal Material(s):	Buna-N/Nitrile Rubber

Technical Info:
Crimp Fitting Socket Data.PDF

O-Ring Base Part Number	Material	Operating Temperature range
FF9446- (Standard)	Buna-N Nitrile rubber 90 Durometer	-40°F to +250°F (-40°C to +121°C)
22033-	EPDM Ethylene propylene diene monomer	-65°F to +212°F (-55°C to +100°C)
22046-	Viton* Fluoroelastomer 90 Durometer	-15°F to +400°F (-25°C to +205°C)
FF9855-	Buna-N Low temperature nitrile rubber 90 Durometer	-65°F to +225°F (-55°C to +107°C)
22546-	Neoprene 90 Durometer	-65°F to +300°F (-55°C to +150°C)


Buna-N (Nitrile) Part Number	Viton Part Number	Low Temperature Buna-N (Nitrile) Part Number	Neoprene Part Number	Tube Size	A	E
FF9446-11 Weatherhead Part #: 4629X4	22046-11	-	-	-04	0.301"	0.07"
FF9446-12 Weatherhead Part #: 4629X6	22046-12	FF9855-12	22546-12	-06	0.364"	0.07"
FF9446-14 Weatherhead Part #: 4629X8	22046-14	FF9855-14	22546-14	-08	0.489"	0.07"
FF9446-16 Weatherhead Part #: 4629X10	22046-16	FF9855-16	22546-16	-10	0.614"	0.07"
FF9446-18 Weatherhead Part #: 4629X12	22046-18	FF9855-18	22546-18	-12	0.739"	0.07"
FF9446-19	-	-	-	-	0.8125"	0.0625"
FF9446-21 Weatherhead Part #: 4629X16	22046-21	-	22546-21	-16	0.926"	0.07"
FF9446-25 Weatherhead Part #: 4629X20	22046-25	-	22546-25	-20	1.176"	0.07"
FF9446-29 Weatherhead Part #: 4629X24	22046-29	-	-	-24	1.489"	0.07"

* Viton is a trademark of The Chemours Company FC, LLC

Danfoss (Eaton - Aeroquip)

Danfoss is a global technology leader in power management solutions that make electrical, hydraulic and mechanical power operate more efficiently, reliably, safely and sustainably. Danfoss hydraulic pumps, motors, transmissions, valves, cylinders, controls, hose and fittings offer a unique combination of proven technology and innovative design that translates directly into reliable performance and enhanced uptime.
