Y001 by Dixon Valve | Y Line Strainer | 20 x 20 Mesh Screen | 1/4" Female NPT x 1/4" Female NPT | Cast Iron

Name: Y001 by Dixon Valve | Y Line Strainer | 20 x 20 Mesh Screen | 1/4" Female NPT x 1/4" Female NPT | Cast Iron
Brand: Dixon
SKU: Y001 Dixon
Price: 35.12 USD
Availability: InStock

Save $0.26

$35.38

$35.38 - $35.38

$35.38

$35.12

$35.12 - $35.12

$35.12

Dixon Valve
Y Line Strainer | Cast Iron

Quantity

Specifications for Variant SKU: Y001 Dixon
Shape (Orientation):	Y
Ends Configuration:	\1/4\ Female NPT, 1/4\ Female NPT, Some Ends Match\
Material(s):	Iron

Features:
Plug ported for blowdown service. No replacement screens available.
Material:
Body: Cast Iron Graphite gasket
Specification:
Working pressure: 500 PSI CWP; 250 PSI SWP Maximum temperature: 406°F (208°C)

Cast Iron Part Number	Female NPT	Mesh Type
Y001	1/4"	20 x 20 Mesh
Y002	3/8"	20 x 20 Mesh
Y003	1/2"	20 x 20 Mesh
Y004	3/4"	20 x 20 Mesh
Y005	1"	20 x 20 Mesh
Y006	1-1/4"	20 x 20 Mesh
Y007	1-1/2"	20 x 20 Mesh
Y008	2"	20 x 20 Mesh

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
