Y003 by Dixon Valve | Y Line Strainer | 20 x 20 Mesh Screen | 1/2" Female NPT x 1/2" Female NPT | Cast Iron

Y003 by Dixon Valve | Y Line Strainer | 20 x 20 Mesh Screen | 1/2" Female NPT x 1/2" Female NPT | Cast Iron

Save $0.31 Save $0.31
$42.60
$42.60 - $42.60
$42.60
$42.29
$42.29 - $42.29
$42.29

Dixon Valve
Y Line Strainer | Cast Iron
Specifications for Variant SKU: Y003 Dixon
Shape (Orientation): Y
Ends Configuration: \1/2\ Female NPT, 1/2\ Female NPT, Some Ends Match\
Material(s): Iron
Features:
  • Plug ported for blowdown service.
  • No replacement screens available.
Material:
  • Body: Cast Iron
  • Graphite gasket
Specification:
  • Working pressure: 500 PSI CWP; 250 PSI SWP
  • Maximum temperature: 406°F (208°C)
Cast Iron
Part Number		 Female NPT Mesh Type
Y001 1/4" 20 x 20 Mesh
Y002 3/8" 20 x 20 Mesh
Y003 1/2" 20 x 20 Mesh
Y004 3/4" 20 x 20 Mesh
Y005 1" 20 x 20 Mesh
Y006 1-1/4" 20 x 20 Mesh
Y007 1-1/2" 20 x 20 Mesh
Y008 2" 20 x 20 Mesh
